Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork Fox Performance Float 34
-
Groupset XT -
Suspension Hardtail -
Motor Bosch 250W 75Nm mid-drive -
Battery Bosch Lithium-ion -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX 34 Float Performance, 3-position, Boost
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano XT M8000 GS Shadow Plus, direct mount
Front Derailleur
N/A
Shift Levers
Shimano XT M8000 I-Spec, B-type
Cassette
Shimano XT M8000, 11-46 tooth, 11-speed
Crank
Miranda Delta, 152mm length, Boost
Chain
KMC X10e
Chain Guide
N/A
Pedals
VP-536, black
Wheels
Front Hub
Front: Modus CLK176F, Boost 15mm x 110mm, Rear: Modus CLK252R, Boost 12mm x 148mm
Rear Hub
Front: Modus CLK176F, Boost 15mm x 110mm, Rear: Modus CLK252R, Boost 12mm x 148mm
Rims
Black Jack Ready 27+ 40c Orbea Custom TLR
Spokes
2.3mm
Tires
Kenda 1184A Havok, 2.8" 120TPI/FB/TLR, eMTB specific
Brakes
Brakes
Shimano M506
Brake Levers
Shimano M506
Cockpit
Stem
Race Face Ride
Handlebar
Orbea OC-II Riser, 760mm width
Headset
FSA Integrated
Seat
Saddle
Selle Royal 2062
Seatpost
Orbea Digit, 400mm length
Motor & Battery
Motor
Bosch Performance CX, 250W
Battery
Bosch Lithium-ion
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.85 mm | 1.72 mm | 1.68 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 305 mm |
| Stack | 628 mm | 628 mm | 651 mm |
| Reach | 339 mm | 365 mm | 388 mm |
| Top Tube Length | 535 mm | 561 mm | 591 mm |
| Seat Tube Angle | 72.9 ° | 72.9 ° | 72.9 ° |
| Seat Tube Length | 340 mm | 360 mm | 402 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 115 mm | 115 mm | 140 mm |
| Chainstay Length | 458 mm | 458 mm | 458 mm |
| Wheelbase | 1089 mm | 1115 mm | 1148 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 50 mm |
| Standover Height | 772 mm | 772 mm | 783 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Wild 20 USA is part of the Orbea E Wild model. 77 e-bikes variations carry this model name so far. You can easily view all of the Orbea E Wild e-bikes models from 2018, here.
Model range prices
Orbea Wild 30 USA 2018 is the cheapest e-bike model and costs 3799$. Orbea Wild FS 10 USA 2018 is the most expensive one and costs 6999$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail e-bikes average price
If you want an acceptable Trail e-bike you should know that the average price is 3365$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
This e-bike was released in 2018 and its price was 4399$. In conclusion, this e-bike price is 30.73% higher than the price of the average Trail e-bike.
Wild 20 USA components
Fork
The Fox Performance Float 34 is included from the factory. It has a travel distance of 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
The wheels on Wild 20 USA are the 27.5″ aluminum type. The 27.5″ wheels are a great choice for smaller riders. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Orbea Wild 20 USA has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
This e-bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, you can easily find one that suits you.
