Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset GRX 800 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 172cm
MD
169cm - 180cm
LG
177cm - 187cm
XL
184cm - 197cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Trail Gravel Flatbar
Suspension Fork
OGV II Disc 12x100
Drivetrain
Rear Derailleur
GRX 800 2x11s Flatbar
Cassette
Ultegra R8000 11-32
Crank
Gossamer Pro 2X 46/30
Pedals
Without pedals
Wheels
Rims
Rapid Red 300
Tires
G-One Speed Perf 35 Race Guard
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
CLS L2
Handlebar
Flat 580 mm
Grips
True grip X Comp
Seat
Saddle
X-LR Air Cross Light SF Rails Ti316
Seatpost
2B WTD 27,2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.58 mm | 1.62 mm | 1.64 mm |
| Front Center | 589 mm | 599 mm | 610 mm | 620 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 69 mm | 66 mm | 63 mm | 60 mm |
| Stack | 562 mm | 586 mm | 611 mm | 631 mm |
| Reach | 363 mm | 370 mm | 377 mm | 385 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm | 545 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 150 mm | 175 mm | 200 mm | 220 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1005 mm | 1016 mm | 1027 mm | 1037 mm |
| Bottom Bracket Drop | 76 mm | 75 mm | 74 mm | 73 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 169 cm | 177 cm | 184 cm |
| Rider Max Height | 172 cm | 180 cm | 187 cm | 197 cm |
About this model
Trail F46 is part of the Origine Trail model. Origine released 16 bikes variations of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Origine Trail F26 2023 is the cheapest bike model and costs 1695$. Origine Trail T56 2023 is the most expensive one and costs 2706$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Gravel bikes
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2297$. In conclusion, this bike price is 7.18% lower than the price of the average Gravel bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
As for the wheels, Origine Trail F46 2023, has a aluminum model. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Origine Trail F46 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Trail F46 comes in 4 sizes, that range from 158 cm – 197 cm (5.18 ft – 6.46 ft). In short, you can easily find one that suits you.
