Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset 105, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
49cm
152cm - 159cm
52cm
156cm - 164cm
54cm
161cm - 174cm
56cm
171cm - 184cm
58cm
181cm - 189cm
60m
187cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Warakin custom butted austenitic stainless steel frame
Suspension Fork
Lithic full carbon fork, 12mm through-axle
Drivetrain
Rear Derailleur
Shimano 105 GS, 11 speed
Front Derailleur
Shimano 105
Shift Levers
Shimano 105 mechanical, 11 speed
Cassette
Shimano 105, 11-32t, 11 speed
Crank
Shimano FC-RS510: 170mm for 49, 52; 172.5mm for 54, 56; 175mm for 58, 60
Bottom Bracket
Shimano english thread BSA, Ø68mm
Chain
Shimano HG-11X
Wheels
Rims
DT Swiss C 1800 SPLINE
Tires
Panaracer Gravel King SK 700x38
Brakes
Brakes
Tektro MD-C550, flat mount
Cockpit
Stem
6061 aluminum
Handlebar
Lithic Corundum aluminum compact drop with 16° flare
Grips
Cork handlebar tape, black
Headset
ZS44/28.6 upper, EC44/40.0 lower
Seat
Saddle
WTB Volt with Otso graphics, 142mm
Seatpost
6061 aluminum
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 60m |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.45 mm | 1.49 mm | 1.55 mm | 1.62 mm | 1.63 mm |
| Bottom Bracket Height | 281 mm | 281 mm | 281 mm | 281 mm | 281 mm | 281 mm |
| Front Center | 619 mm | 606 mm | 612 mm | 617 mm | 621 mm | 635 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 72 mm | 71 mm | 70 mm | 67.5 mm | 65 mm | 65 mm |
| Stack | 542 mm | 551 mm | 572 mm | 598 mm | 624 mm | 643 mm |
| Reach | 372 mm | 380 mm | 383 mm | 385 mm | 386 mm | 394 mm |
| Top Tube Length | 512 mm | 532 mm | 547 mm | 567 mm | 582 mm | 602 mm |
| Seat Tube Length | 470 mm | 505 mm | 530 mm | 550 mm | 570 mm | 590 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71.5 ° | 72 ° | 72 ° |
| Head Tube Length | 87 mm | 95 mm | 115 mm | 140 mm | 165 mm | 185 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1032 mm | 1019 mm | 1025 mm | 1030 mm | 1034 mm | 1048 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 732 mm | 762 mm | 782 mm | 802 mm | 822 mm | 842 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 152 cm | 156 cm | 161 cm | 171 cm | 181 cm | 187 cm |
| Rider Max Height | 159 cm | 164 cm | 174 cm | 184 cm | 189 cm | 195 cm |
About this model
Warakin Stainless is an Otso Warakin model. 36 bikes variations carry this model name so far. Take a sneak peek at all Otso Warakin bikes models from 2023, by clicking here.
Model range prices
Otso Warakin Stainless – GRX 11-Speed Sale 1×11 Shimano GRX 600 2023 is the cheapest bike model and costs 2662$. Otso Warakin Ti 1×13 Campagnolo Ekar 2023 is the most expensive one and costs 6550$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Gravel bikes
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2023 and its price was 2662$. Doing a quick comparison, we notice that Warakin Stainless price is 8.12% higher than the average cost of a Gravel bike.
Warakin Stainless components
Fork material
Warakin Stainless has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
The Warakin Stainless 2023 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Otso Warakin Stainless is equipped with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
Otso Warakin Stainless bike has 6 sizes, in the range of 152 cm – 195 cm (4.99 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
