Otso Warakin Ti 1×12 Shimano GRX 800 2023
2023 Road
Estimate price |
5,150$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Titanium -
Wheels 700c -
Groupset Shimano -
Suspension Rigid -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
49cm
152cm - 159cm
52cm
156cm - 164cm
54cm
161cm - 174cm
56cm
171cm - 184cm
58cm
181cm - 189cm
60m
187cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Seamless 3Al-2.5V B338 grade 9 titanium, internally butted front triangle
Suspension Fork
Lithic Hiili Carbon Fork with Triple Mounts, 12x100mm
Drivetrain
Cassette
NEW 1x12 Shimano GRX 800 (10-51T cassette)
Crank
40T Round - Stock Shimano
Bottom Bracket
68mm BSA threaded
Wheels
Rims
SUNringle G30 Expert 700c 26mm
Tires
Schwalbe G-One Allround 700x45 Black
Brakes
Brakes
Hydraulic Disc
Cockpit
Handlebar
Lithic Corundum 40cm
Headset
Wolf Tooth Performance Headset - Black
Seat
Saddle
WTB Volt Medium, 142mm width
Seatpost
Aluminum 27.2 350mm - Black
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 60m |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.45 mm | 1.49 mm | 1.55 mm | 1.62 mm | 1.63 mm |
| Bottom Bracket Height | 281 mm | 281 mm | 281 mm | 281 mm | 281 mm | 281 mm |
| Front Center | 619 mm | 606 mm | 612 mm | 617 mm | 621 mm | 635 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 72 mm | 71 mm | 70 mm | 67.5 mm | 65 mm | 65 mm |
| Stack | 542 mm | 551 mm | 572 mm | 598 mm | 624 mm | 643 mm |
| Reach | 372 mm | 380 mm | 383 mm | 385 mm | 386 mm | 394 mm |
| Top Tube Length | 512 mm | 532 mm | 547 mm | 567 mm | 582 mm | 602 mm |
| Seat Tube Length | 470 mm | 505 mm | 530 mm | 550 mm | 570 mm | 590 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71.5 ° | 72 ° | 72 ° |
| Head Tube Length | 87 mm | 95 mm | 115 mm | 140 mm | 165 mm | 185 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1032 mm | 1019 mm | 1025 mm | 1030 mm | 1034 mm | 1048 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 732 mm | 762 mm | 782 mm | 802 mm | 822 mm | 842 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 152 cm | 156 cm | 161 cm | 171 cm | 181 cm | 187 cm |
| Rider Max Height | 159 cm | 164 cm | 174 cm | 184 cm | 189 cm | 195 cm |
Model Overview
Warakin Ti 1×12 Shimano GRX 800 is part of the Otso Warakin model. Otso released 36 bikes variations of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Otso Warakin Stainless – GRX 11-Speed Sale 1×11 Shimano GRX 600 2023 is the most economical model, with a starting price of 2662$. Otso Warakin Ti 1×13 Campagnolo Ekar 2023 on the other hand costs 6550$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Gravel bikes average price
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Otso Warakin Ti 1×12 Shimano GRX 800 price was 5150$. Doing a quick comparison, we notice that Warakin Ti 1×12 Shimano GRX 800 price is 109.18% higher than the average cost of a Gravel bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
When it comes to wheels, the Warakin Ti 1×12 Shimano GRX 800 bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Otso Warakin Ti 1×12 Shimano GRX 800 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
There are 6 sizes available for this model. Rider height can be anywhere between 152 cm – 195 cm (4.99 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
