Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Groupset NX Eagle, Race Face -
Suspension Rigid -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 169cm
MD
166cm - 179cm
LG
176cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
REYNOLDS 725 STEEL FRAME, INTERNAL CABLE ROUTING FOR DROPPER SEAT POST, SLIDING DROPOUTS – SINGLE SPEED / ROLHOFF COMPATIBLE, UDH OPTION (AVAILABLE JUNE 2024), POST MOUNT BRAKE STD, REAR RACK MOUNT, TRIPLE WATER BOTTLE MOUNT UNDER AND ON TOP OF THE DOWNTUBE, GAS TANK MOUNT ON TOP OF TOP TUBE, ELECTRODEPOSITION SURFACE TREATMENT (CORROSION PROTECTION), 12MMX148MM BOOST REAR SPACING, 73mm BSA BOTTOM BRACKET, TAPERED 1-1/2¨ x 1-1/8¨ HEAD TUBE, DIA 34.9MM SEAT POST CLAMP, DIA 31.6MM SEAST POST, HEADSET: TOP ZS44 LOWER ZS56, MAXIMUM TIRE CLEARANCE: 29¨X2.8¨; 27.5¨X3¨
Suspension Fork
100% CARBON, TRIPLE CARGO CAGE MOUNTS, 15MMX110MM BOOST SPACING, TAPERED STEER TUBE 1-1/8¨ / 1-1/2¨, MAX TIRE CLEARANCE
Drivetrain
Rear Derailleur
SRAM NX EAGLE
Shift Levers
SRAM NX EAGLE
Cassette
SRAM PG-1230 11-50T
Crank
RACE FACE AEFFECT, 32T, CHAINRING
Bottom Bracket
RACE FACE BSA TEAM
Chain
KMC X12
Pedals
Not included
Wheels
Rims
WTB STi30 / SHIMANO TC500 (FRONT) / TC600 (REAR), 32 HOLES, CENTERLOCK, MICROSPLINE
Tires
MAXXIS REKON, 29X2.6, EXO/TR, 60TPI, TANWALL
Brakes
Brakes
SRAM LEVEL
Cockpit
Stem
RITCHEY MTB trail, Alloy BBK 31.8X45mm
Handlebar
RITCHEY MTN Comp 10D Rizer, 31.8x800mm, 20mm rise, 10D backswept
Headset
FSA NO.57E
Seat
Saddle
WTB PURE
Seatpost
DROPPER POST KS E20I (100mm, 125mm or 150mm depending on frame size)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.36 mm | 1.3 mm |
| Bottom Bracket Height | 309 mm | 309 mm | 309 mm |
| Front Center | 717 mm | 740 mm | 771 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 105 mm | 105 mm | 105 mm |
| Stack | 609 mm | 619 mm | 628 mm |
| Reach | 437 mm | 456 mm | 483 mm |
| Top Tube Length | 598 mm | 620 mm | 649 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 390 mm | 425 mm | 460 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 444 mm | 444 mm | 444 mm |
| Wheelbase | 1153 mm | 1176 mm | 1207 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Standover Height | 687 mm | 722 mm | 757 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 154 cm | 166 cm | 176 cm |
| Rider Max Height | 169 cm | 179 cm | 188 cm |
Model Overview
Taïga SRAM NX is part of the Panorama Taiga model. 10 bikes variations carry this model name so far. Take a sneak peek at all Panorama Taiga bikes models from 2023, by clicking here.
Model range prices
The most economical model, the Panorama Taïga SRAM NX 2023 has a starting price of 2132$. Panorama Taïga EXP RIVAL + RATIO TECHNOLOGY 2023 on the other hand is the most expensive at 2855$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2023 for 2132$. In conclusion, this bike price is 29.55% lower than the price of the average Trail bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
When it comes to wheels, the Taïga SRAM NX bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Taïga SRAM NX comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 154 cm – 188 cm (5.05 ft – 6.17 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Panorama Taïga SRAM NX includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
