Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Carbon -
Wheels 27.5" -
Suspension Full
Sizing
Recommended size guide.
SM
162cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
187cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Phoenix
Rear Shock
Fox Factory Float X2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.43 mm | 1.35 mm | 1.27 mm |
| Bottom Bracket Height | 340 mm | 340 mm | 340 mm | 340 mm |
| Stack | 608 mm | 608 mm | 608 mm | 608 mm |
| Reach | 397 mm | 425 mm | 452 mm | 479 mm |
| Top Tube Length | 600 mm | 626 mm | 651 mm | 677 mm |
| Seat Tube Angle | 71.85 ° | 71.85 ° | 71.85 ° | 71.85 ° |
| Seat Tube Length | 431 mm | 431 mm | 431 mm | 431 mm |
| Head Tube Angle | 62.5 ° | 62.5 ° | 62.5 ° | 62.5 ° |
| Head Tube Length | 106 mm | 106 mm | 106 mm | 106 mm |
| Chainstay Length | 439 mm | 439 mm | 439 mm | 439 mm |
| Wheelbase | 1208 mm | 1235 mm | 1265 mm | 1288 mm |
| Bottom Bracket Drop | 15 mm | 15 mm | 15 mm | 15 mm |
| Standover Height | 734 mm | 734 mm | 734 mm | 734 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 162 cm | 171 cm | 179 cm | 187 cm |
| Rider Max Height | 174 cm | 182 cm | 189 cm | 200 cm |
Model Overview
Phoenix Frame completes the Pivot Phoenix model. There are 35 frames that carry this model name. You can easily view all of the Pivot Phoenix frames models from 2019, here.
Model range prices
The most economical model, the Pivot Phoenix Team Frame 2019 has a starting price of 1599$. Pivot Phoenix 29 Team Frame Kit 2019 on the other hand is the most expensive at 5699$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Downhill frames
If you want to purchase a solid Downhill frame, it is important to know that the average cost is 1923$. However, you could also get a good Downhill frame even if you pay a lower amount than the average price. In short, before purchasing your ideal frame do some research about its components, and also check for reviews online.
At the moment of the release date, Pivot Phoenix Frame price was 1599$. Doing a quick comparison, we notice that Phoenix Frame price is 20.26% lower than the average cost of a Downhill frame.
Phoenix Frame components
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 162 cm – 200 cm (5.31 ft – 6.56 ft). In conclusion, you won’t have a problem finding one that suits you.
