Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 203mm -
Fork Marzocchi Bomber 58
-
Groupset Zee -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
187cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Phoenix
Suspension Fork
Marzocchi Bomber 58 27.5", 52mm offset, GRIP - 203mm
Rear Shock
Fox Factory Float X2
Drivetrain
Rear Derailleur
Shimano Zee 10-Speed
Shift Levers
Shimano Zee M640 10-Speed
Cassette
Shimano 105 CS-5700 11-28t
Crank
Shimano Zee 36t
Chain
Shimano CN-6701 10-Speed
Wheels
Rims
Sun Ringle ADD Comp - 27.5"
Tires
Maxxis Assegai 27.5" x 2.5" 3C, MAXXGRIP, DH CASING TRMaxxis Assegai 27.5" x 2.5" 3C, MAXXGRIP, DH CASING TR
Brakes
Brakes
Shimano Zee M640 4-piston
Disk Rotors
Shimano SLX 6-bolt - 203mm Shimano SLX 6-bolt - 180mm
Cockpit
Stem
Phoenix Team DH - 45mm
Handlebar
Phoenix Race Low Rise Aluminum
Grips
Phoenix Team Padloc
Headset
Pivot Precision Sealed Cartridge - DH
Seat
Saddle
Phoenix WTB Race High Tail
Seatpost
Phoenix Race Aluminum
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.43 mm | 1.35 mm | 1.27 mm |
| Bottom Bracket Height | 340 mm | 340 mm | 340 mm | 340 mm |
| Stack | 608 mm | 608 mm | 608 mm | 608 mm |
| Reach | 397 mm | 425 mm | 452 mm | 479 mm |
| Top Tube Length | 600 mm | 626 mm | 651 mm | 677 mm |
| Seat Tube Angle | 71.85 ° | 71.85 ° | 71.85 ° | 71.85 ° |
| Seat Tube Length | 431 mm | 431 mm | 431 mm | 431 mm |
| Head Tube Angle | 62.5 ° | 62.5 ° | 62.5 ° | 62.5 ° |
| Head Tube Length | 106 mm | 106 mm | 106 mm | 106 mm |
| Chainstay Length | 439 mm | 439 mm | 439 mm | 439 mm |
| Wheelbase | 1208 mm | 1235 mm | 1265 mm | 1288 mm |
| Bottom Bracket Drop | 15 mm | 15 mm | 15 mm | 15 mm |
| Standover Height | 734 mm | 734 mm | 734 mm | 734 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 162 cm | 171 cm | 179 cm | 187 cm |
| Rider Max Height | 174 cm | 182 cm | 189 cm | 200 cm |
About this model
Phoenix Race Zee belongs to the Pivot Phoenix model. 35 bikes variations carry this model name so far. Take a sneak peek at all Pivot Phoenix bikes models from 2020, by clicking here.
Model range prices
The most economical model, the Pivot Phoenix Race Zee 2020 has a starting price of 3899$. Pivot Phoenix 29 Pro Saint 2020 on the other hand is the most expensive at 7599$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Downhill bikes average price
If you want an acceptable Downhill bike you should know that the average price is 3391$. However, you could also get a good Downhill bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2020 and its price was 3899$. Doing a quick comparison, we notice that Phoenix Race Zee price is 14.98% more expensive than the average cost of a Downhill bike.
Overview of components
Fork
The Marzocchi Bomber 58 is included from the factory. It has a travel distance of 203mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
As for the wheels, Pivot Phoenix Race Zee 2020, has a 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Phoenix Race Zee comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Pivot Phoenix Race Zee bike has 4 sizes, in the range of 162 cm – 200 cm (5.31 ft – 6.56 ft). In conclusion, it won’t take much to find one that’s right for you.
