Pivot Shuttle LT Ride SLX/XT 2023
2023 E-bike
Estimate price |
9,899$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 170mm -
Fork Fox Performance Float 38
-
Groupset XT, SLX -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
187cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Shuttle LT Shimano
Suspension Fork
Fox Performance E-MTB 38 29", 44mm offset, GRIP - 170mm
Rear Shock
Fox Performance Float X
Drivetrain
Rear Derailleur
Shimano XT M8100 SGS 12-Speed
Shift Levers
Shimano SLX M7100 ISPEC EV 12-Speed
Cassette
Shimano Deore M6100 10-51t
Crank
Shimano EM600 E-MTB 34t
Chain
Shimano CN-M6100 12 Speed
Wheels
Rims
DT Swiss Hybrid H1900. 30mm - 29"
15x110 F/12x157 R
Tires
Maxxis Assegai 29" x 2.5" TR, EXO+, 3C
Maxxis Assegai 29" x 2.5" TR, EXO+, 3C
Brakes
Brakes
Shimano SLX M7120 4-piston
Cockpit
Stem
Phoenix Team Enduro/Trail
Handlebar
Phoenix Race Low Rise Aluminum
Grips
Phoenix Factory Lock-On
Headset
Pivot Precision Sealed Cartridge
Seat
Saddle
WTB High Tail Trail Race (SM), Phoenix WTB Pro Volt (Medium Width) (MD), Pivot Pro E-Bike (LG-XL)
Seatpost
E13 Vario 150mm - 180mm (SM-LG), 180mm - 210mm (XL)
Motor & Battery
Motor
Shimano Steps DU-EP800
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.37 mm | 1.34 mm | 1.3 mm |
| Bottom Bracket Height | 352 mm | 352 mm | 352 mm | 352 mm |
| Front Center | 794 mm | 817 mm | 842 mm | 868 mm |
| Rake | 45 mm | 41 mm | 41 mm | 41 mm |
| Trail | 133 mm | 137 mm | 137 mm | 137 mm |
| Stack | 639 mm | 648 mm | 657 mm | 666 mm |
| Reach | 449 mm | 472 mm | 492 mm | 514 mm |
| Top Tube Length | 609 mm | 634 mm | 654 mm | 673 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 77 ° | 77.5 ° |
| Seat Tube Length | 370 mm | 400 mm | 430 mm | 470 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1238 mm | 1261 mm | 1286 mm | 1312 mm |
| Bottom Bracket Drop | 22 mm | 22 mm | 22 mm | 22 mm |
| Standover Height | 690 mm | 694 mm | 696 mm | 697 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 162 cm | 171 cm | 179 cm | 187 cm |
| Rider Max Height | 174 cm | 182 cm | 189 cm | 200 cm |
Model Overview
Shuttle LT Ride SLX/XT completes the Pivot E Shuttle Lt model. 4 e-bikes variations carry this model name so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
The most economical model, the Pivot Shuttle LT Ride SLX/XT 2023 has a starting price of 9899$. Pivot Shuttle LT Team XTR 2023 on the other hand is the most expensive at 11999$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Enduro e-bikes
According to our math, the average price for a trustworthy Enduro e-bike is 4785$. However, even though the average price of an Enduro e-bike is lower, you might still be able to get a top-quality e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
This e-bike was released in 2023 and its price was 9899$. If we compare this with the average Enduro e-bike cost we notice that the price is 106.88% higher.
Shuttle LT Ride SLX/XT components
Fork
The fork installed on this bike is the Fox Performance Float 38 model. The travel on this model is 170mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
The Shuttle LT Ride SLX/XT 2023 e-bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. Pivot Shuttle LT Ride SLX/XT is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Pivot Shuttle LT Ride SLX/XT e-bike has 4 sizes, in the range of 162 cm – 200 cm (5.31 ft – 6.56 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Pivot Shuttle LT Ride SLX/XT comes with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
