Pivot Shuttle LT Team XTR 2023
2023 E-bike
Estimate price |
11,999$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 170mm -
Fork Fox Factory Float 38
-
Groupset XTR, Shimano -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
187cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Shuttle LT Shimano
Suspension Fork
Fox Factory E-MTB 38 29", 44mm offset, GRIP2 - 170mm
Rear Shock
Fox Factory Float X
Drivetrain
Rear Derailleur
Shimano XTR M9100 SGS 12-Speed
Shift Levers
Shimano XTR M9100 ISPEC EV 12-Speed
Cassette
Shimano XT M8100 10-51t
Crank
Shimano EM600 E-MTB 34t
Chain
Shimano CN-M8100 12-Speed
Wheels
Rims
DT Swiss Hybrid HX1501, 30mm - 29"
15x110 F/12x157 R
Tires
Maxxis Assegai 29" x 2.5" TR, EXO+, 3C
Maxxis Assegai 29" x 2.5" TR, EXO+, 3C
Brakes
Brakes
Shimano XTR M9120 4-piston
Cockpit
Stem
Phoenix Team Enduro/Trail
Handlebar
Phoenix Team Low Rise Carbon
Grips
Phoenix Factory Lock-On
Headset
Pivot Precision Sealed Cartridge
Seat
Saddle
WTB High Tail Trail Pro (SM), Phoenix WTB Pro Volt (Medium Width) (MD), Pivot Pro E-Bike (LG-XL)
Seatpost
Fox Transfer Factory Series 150mm (SM), 175mm (MD-LG), 200mm (XL)
Motor & Battery
Motor
Shimano Steps DU-EP800
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.37 mm | 1.34 mm | 1.3 mm |
| Bottom Bracket Height | 352 mm | 352 mm | 352 mm | 352 mm |
| Front Center | 794 mm | 817 mm | 842 mm | 868 mm |
| Rake | 45 mm | 41 mm | 41 mm | 41 mm |
| Trail | 133 mm | 137 mm | 137 mm | 137 mm |
| Stack | 639 mm | 648 mm | 657 mm | 666 mm |
| Reach | 449 mm | 472 mm | 492 mm | 514 mm |
| Top Tube Length | 609 mm | 634 mm | 654 mm | 673 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 77 ° | 77.5 ° |
| Seat Tube Length | 370 mm | 400 mm | 430 mm | 470 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1238 mm | 1261 mm | 1286 mm | 1312 mm |
| Bottom Bracket Drop | 22 mm | 22 mm | 22 mm | 22 mm |
| Standover Height | 690 mm | 694 mm | 696 mm | 697 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 162 cm | 171 cm | 179 cm | 187 cm |
| Rider Max Height | 174 cm | 182 cm | 189 cm | 200 cm |
Model Overview
Shuttle LT Team XTR is a Pivot E Shuttle Lt model. There are 4 e-bikes that carry this model name. Take a sneak peek at all Pivot E Shuttle Lt e-bikes models from 2023, by clicking here.
Model range prices
The most economical model, the Pivot Shuttle LT Ride SLX/XT 2023 has a starting price of 9899$. Pivot Shuttle LT Team XTR 2023 on the other hand is the most expensive at 11999$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Enduro e-bikes
According to our calculations, the average cost of an Enduro e-bike that is reliable is 4785$. However, even though the average price of an Enduro e-bike is lower, you might still be able to get a top-quality e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 11999$. Doing a quick comparison, we notice that Shuttle LT Team XTR price is 150.76% more expensive than the average cost of an Enduro e-bike.
Shuttle LT Team XTR components
Fork
The fork installed on this bike is the Fox Factory Float 38 model. The travel on this model is 170mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
When leaving the production line, the Shuttle LT Team XTR model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
For your safety, it is important to have quality breaks on your bike. Pivot Shuttle LT Team XTR has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
This e-bike is available in 4 sizes. They vary from 162 cm – 200 cm (5.31 ft – 6.56 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
The Pivot model is also equipped with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
