Pivot Shuttle SL Ride SLX/XT 2023
2023 E-bike
Estimate price |
8,999$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 150mm -
Fork Fox Performance Float 36
-
Groupset XT, SLX -
Suspension Full -
Motor Fazua mid-drive -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
187cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Shuttle SL
Suspension Fork
Fox Performance E-MTB 36 29", 44mm offset, GRIP - 150mm
Rear Shock
Fox Performance Float X
Drivetrain
Rear Derailleur
Shimano XT M8100 SGS 12-Speed
Shift Levers
Shimano SLX M7100 ISPEC EV 12-Speed
Cassette
Shimano SLX M7100 10-51t
Crank
PRAXIS ETOR E-MTB 32t
Chain
Shimano CN-M7100 12-Speed
Wheels
Rims
DT Swiss M1900 w/ DT Swiss 370 hub, 30mm - 29"
15x110 F/12x157 R
Tires
Maxxis Dissector 29" x 2.4" WT, TR, 3C, EXO, MAXXTERRA
Maxxis Dissector 29" x 2.4" WT, TR, 3C, EXO, MAXXTERRA
Brakes
Brakes
Shimano SLX M7120 4-piston
Cockpit
Stem
Phoenix Team Enduro/Trail
Handlebar
Phoenix Race Low Rise Aluminum -780mm
Grips
Phoenix Factory Lock-On
Headset
Pivot Precision Sealed Cartridge
Seat
Saddle
Phoenix WTB Volt Race (Medium Width)
Seatpost
E13 Vario 150mm - 180mm (SM-MD), 180mm - 210mm (LG-XL)
Motor & Battery
Motor
FAZUA RIDE 60
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.34 mm | 1.32 mm | 1.28 mm |
| Bottom Bracket Height | 347 mm | 347 mm | 347 mm | 347 mm |
| Front Center | 755 mm | 792 mm | 807 mm | 835 mm |
| Rake | 43 mm | 43 mm | 43 mm | 44 mm |
| Trail | 127 mm | 127 mm | 127 mm | 126 mm |
| Stack | 612 mm | 628 mm | 632 mm | 644 mm |
| Reach | 437 mm | 467 mm | 480 mm | 502 mm |
| Top Tube Length | 600 mm | 634 mm | 648 mm | 662 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76.8 ° |
| Seat Tube Length | 368 mm | 394 mm | 432 mm | 470 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 95 mm | 112 mm | 117 mm | 130 mm |
| Chainstay Length | 434 mm | 434 mm | 436 mm | 440 mm |
| Wheelbase | 1188 mm | 1225 mm | 1242 mm | 1274 mm |
| Bottom Bracket Drop | 27 mm | 27 mm | 27 mm | 27 mm |
| Standover Height | 667 mm | 670 mm | 676 mm | 680 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 162 cm | 171 cm | 179 cm | 187 cm |
| Rider Max Height | 174 cm | 182 cm | 189 cm | 200 cm |
About this model
Shuttle SL Ride SLX/XT is part of the Pivot E Shuttle Sl model. There are 9 e-bikes that carry this model name. Take a sneak peek at all Pivot E Shuttle Sl e-bikes models from 2023, by clicking here.
Model range prices
Pivot Shuttle SL Ride SLX/XT 2023 is the most economical model, with a starting price of 8999$. Pivot Shuttle SL World Cup XTR 2023 on the other hand costs 13199$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Enduro e-bikes
According to our math, the average price for a trustworthy Enduro e-bike is 4785$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
This e-bike was released in 2023 and its price was 8999$. Comparing the average cost of an Enduro e-bike to this one, you will see that Shuttle SL Ride SLX/XT price is 88.07% more expensive.
Overview of components
Fork
The Shuttle SL Ride SLX/XT comes factory-installed with the Fox Performance Float 36 fork. This has a travel range of 150mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
When leaving the production line, the Shuttle SL Ride SLX/XT model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Shuttle SL Ride SLX/XT comes in 4 sizes, that range from 162 cm – 200 cm (5.31 ft – 6.56 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Pivot Shuttle SL Ride SLX/XT includes a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
