Pivot Shuttle SL World Cup XTR 2023
2023 E-bike
Estimate price |
13,199$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 140mm -
Fork Fox Factory Float 34
-
Groupset XTR -
Suspension Full -
Motor Fazua mid-drive -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
187cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Shuttle SL
Suspension Fork
Fox Factory E-MTB 34 29", 44mm offset, FIT4 - 140mm
Rear Shock
Fox Factory Float DPS
Drivetrain
Rear Derailleur
Shimano XTR SGS 12-Speed
Shift Levers
Shimano XTR M9100 ISPEC EV 12-Speed
Cassette
Shimano XTR M9100 10-51t
Crank
ROTOR EKAPIC E-MTB 32t
Chain
Shimano CN-M9100 12-Speed
Wheels
Rims
Reynolds Blacklabel 309/289 XC w/ Industry Nine Hydra hub 30mm F 28mm R - 29"
15x110 F/12x157 R
Tires
Maxxis Rekon 29" x 2.4" WT, TR, 3C, EXO, MAXXTERRA
Maxxis Rekon 29" x 2.4" WT, TR, 3C, EXO, MAXXTERRA
Brakes
Brakes
Shimano XTR M9120 4-piston
Cockpit
Stem
Phoenix Team Enduro/Trail
Handlebar
Phoenix Team Low Rise Carbon -780mm
Grips
Phoenix Factory Lock-On
Headset
Pivot Precision Sealed Cartridge
Seat
Saddle
Phoenix WTB World Cup Volt (Medium Width) - carbon rails
Seatpost
KS LEV Ci 150mm (SM) 175mm (MD-XL)
Motor & Battery
Motor
FAZUA RIDE 60
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.34 mm | 1.32 mm | 1.28 mm |
| Bottom Bracket Height | 347 mm | 347 mm | 347 mm | 347 mm |
| Front Center | 755 mm | 792 mm | 807 mm | 835 mm |
| Rake | 43 mm | 43 mm | 43 mm | 44 mm |
| Trail | 127 mm | 127 mm | 127 mm | 126 mm |
| Stack | 612 mm | 628 mm | 632 mm | 644 mm |
| Reach | 437 mm | 467 mm | 480 mm | 502 mm |
| Top Tube Length | 600 mm | 634 mm | 648 mm | 662 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76.8 ° |
| Seat Tube Length | 368 mm | 394 mm | 432 mm | 470 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 95 mm | 112 mm | 117 mm | 130 mm |
| Chainstay Length | 434 mm | 434 mm | 436 mm | 440 mm |
| Wheelbase | 1188 mm | 1225 mm | 1242 mm | 1274 mm |
| Bottom Bracket Drop | 27 mm | 27 mm | 27 mm | 27 mm |
| Standover Height | 667 mm | 670 mm | 676 mm | 680 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 162 cm | 171 cm | 179 cm | 187 cm |
| Rider Max Height | 174 cm | 182 cm | 189 cm | 200 cm |
About this model
Shuttle SL World Cup XTR is part of the Pivot E Shuttle Sl model. Pivot launched 9 e-bikes of this model so far. Take a sneak peek at all Pivot E Shuttle Sl e-bikes models from 2023, by clicking here.
Model range prices
Pivot Shuttle SL Ride SLX/XT 2023 is the most economical model, with a starting price of 8999$. Pivot Shuttle SL World Cup XTR 2023 on the other hand costs 13199$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail e-bikes average price
Our math shows that the average cost of a dependable Trail e-bike is 3365$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
At the moment of the release date, Pivot Shuttle SL World Cup XTR price was 13199$. Doing a quick comparison, we notice that Shuttle SL World Cup XTR price is 292.24% more expensive than the average cost of a Trail e-bike.
Shuttle SL World Cup XTR components
Fork
Pivot Shuttle SL World Cup XTR 2023 e-bike is equipped with the Fox Factory Float 34 fork, and has 140mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
The wheels on Shuttle SL World Cup XTR are the 29″ carbon type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Pivot Shuttle SL World Cup XTR e-bike has 4 sizes, in the range of 162 cm – 200 cm (5.31 ft – 6.56 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Pivot Shuttle SL World Cup XTR comes with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
