Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 131mm -
Fork RockShox Pike RC
-
Groupset GX Eagle -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Pike RC, Boost, 15mm x 110mm
Rear Shock
RockShox Monarch RT3, 190mm x 51mm, DebonAir, HL tune, High Volume
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12-speed
Front Derailleur
None
Shift Levers
SRAM GX Eagle, 12-speed
Cassette
SRAM Eagle, 12-speed
Crank
SRAM GX Eagle, Boost
Bottom Bracket
SRAM DUB, 73mm threaded
Chain
SRAM GX Eagle, 12-speed
Chain Guide
OneUp Components
Pedals
None
Wheels
Front Hub
Mavic XA35 27.5" wheelset, 15mm x 110mm, 148mm x 12mm
Rear Hub
Mavic XA35 27.5" wheelset, 15mm x 110mm, 148mm x 12mm
Rims
Mavic XA35 27.5" wheelset
Spokes
Mavic XA35 27.5" wheelset
Tires
Maxxis Rekon+ 27.5" x 2.8", EXO, TR
Brakes
Brakes
SRAM Level TL, 180mm rotors
Brake Levers
SRAM Level TL
Cockpit
Stem
Race Face Chester, 40mm
Handlebar
Race Face Chester Riser, 35mm diameter
Grips
Race Face Love Handle
Headset
Cane Creek Forty, ZS44/ZS56
Seat
Saddle
Ergon
Seatpost
Bikeyoke Revive, 125mm on S, 160mm on M/L/XL
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.29 mm | 1.21 mm | 1.16 mm |
| Bottom Bracket Height | 375 mm | 375 mm | 375 mm | 375 mm |
| Front Center | 790 mm | 820 mm | 850 mm | 875 mm |
| Rake | 37 mm | 37 mm | 37 mm | 37 mm |
| Trail | 125 mm | 125 mm | 125 mm | 125 mm |
| Stack | 623 mm | 623 mm | 623 mm | 623 mm |
| Reach | 453 mm | 483 mm | 513 mm | 538 mm |
| Top Tube Length | 587 mm | 617 mm | 647 mm | 672 mm |
| Seat Tube Angle | 78 ° | 78 ° | 78 ° | 78 ° |
| Seat Tube Length | 420 mm | 440 mm | 480 mm | 510 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 135 mm | 135 mm | 135 mm | 135 mm |
| Chainstay Length | 458 mm | 458 mm | 458 mm | 458 mm |
| Wheelbase | 1247 mm | 1277 mm | 1307 mm | 1332 mm |
| Bottom Bracket Drop | -20 mm | -20 mm | -20 mm | -20 mm |
| Standover Height | 721 mm | 721 mm | 721 mm | 721 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Evolink 131 TR+ belongs to the Pole Evolink model. Pole released 25 bikes variations of this model so far. You can get a glimpse at all models from 2020, by clicking on this link.
Model range prices
The most economical model, the Pole Evolink 110 TR 2020 has a starting price of 3150$. Pole Evolink 158 LE Coil 2020 on the other hand is the most expensive at 8110$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3540$. Comparing this to the average Trail bike price, we see that the price is 28.17% higher.
Overview of components
Fork
This bike has the RockShox Pike RC fork installed. The fork’s travel is 140mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
From the factory, it comes with the RockShox Monarch RT3 rear shock model, which has a travel of 131mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
The Evolink 131 TR+ 2020 bike is equipped with 27.5″ aluminum wheels when leaving the factory. These wheels will provide you with more control over the bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Evolink 131 TR+ comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Pole Evolink 131 TR+ bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
The Pole model is also equipped with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
