Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork SunTour
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
152cm - 165cm
MD
162cm - 175cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUTECH XC SPORT 27.5"
Suspension Fork
SUNTOUR XCE, 100MM 27.5" TRAVEL
Rear Shock
-
Drivetrain
Rear Derailleur
SHIMANO RD-TY300 6/7-SPEED DA
Shift Levers
SHIMANO ST-EF41 3X7 SPEED
Cassette
SHIMANO TZ500 7-SPEED 14-28T
Crank
WHEELTOP TCSH2-CFPG 42/34/24T 170 MM
Bottom Bracket
CARTRIDGE BB
Chain
KMC HV-500 7-SPEED
Wheels
Rims
DOUBLE WALL ALLOY RIMS W/ ALLOY HUBS
Tires
PERFORMANCE TIRE 27.5" X2.1
Brakes
Brakes
TEKTRO MD-M280 DISC BRAKE
Cockpit
Stem
ENTITY OE E: 45MM, BB: 31.8MM
Handlebar
STEEL W:680MM R:40MM BB:31.8MM
Seat
Saddle
FOMING STEEL RAIL
Seatpost
ENTITY SPORT, 15MM OFFSET, 27.2MMX350MM
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD |
|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.48 mm |
| Bottom Bracket Height | 303 mm | 303 mm |
| Front Center | 640 mm | 660 mm |
| Rake | 42 mm | 42 mm |
| Trail | 91 mm | 91 mm |
| Stack | 599.1 mm | 603.8 mm |
| Reach | 389.7 mm | 408.2 mm |
| Top Tube Length | 571 mm | 591 mm |
| Seat Tube Angle | 73 ° | 73 ° |
| Seat Tube Length | 406 mm | 456 mm |
| Head Tube Angle | 69 ° | 69 ° |
| Head Tube Length | 100 mm | 105 mm |
| Chainstay Length | 436 mm | 436 mm |
| Wheelbase | 1071 mm | 1092 mm |
| Bottom Bracket Drop | 47 mm | 47 mm |
| Standover Height | 706 mm | 748 mm |
| Wheels | 27" | 27" |
| Rider Min Height | 152 cm | 162 cm |
| Rider Max Height | 165 cm | 175 cm |
About this model
CASCADE 3 is part of the Polygon Cascade model. Polygon launched 15 bikes of this model so far. Check out the entire range from 2021 of this model, by clicking this link.
Model range prices
The most economical model, the Polygon CASCADE 2 2021 has a starting price of 469$. Polygon CASCADE 4 2021 on the other hand is the most expensive at 599$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Polygon released this model in 2021, its price was 539$. Comparing the average cost of a Crosscountry bike to this one, you will see that CASCADE 3 price is 253.43% lower.
Overview of components
Fork
This bike has the SunTour fork installed. The fork’s travel is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
The CASCADE 3 2021 bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The CASCADE 3 comes with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
Polygon CASCADE 3 bike has 2 sizes, in the range of 152 cm – 175 cm (4.99 ft – 5.74 ft). In conclusion, finding one for you shouldn’t be a problem.
