Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Deore, Shimano -
Suspension Rigid -
Battery SHIMANO BT-E8010, 504W h -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
160cm - 171cm
LG
169cm - 181cm
XL
179cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
aluminum
Suspension Fork
FULL CARBON RIGID FORK
Rear Shock
-
Drivetrain
Rear Derailleur
SHIMANO DEORE RD-6000SGS
Shift Levers
SHIMANO DEORE SL-6000-R
Cassette
SHIMANO DEORE CS-HG500, 11-34T
Crank
CHAINWHEEL SHIMANO FC-E5010 170MM (43-49MM) 175MM (52MM), CHAINRING SHIMANO SM-CRE50 44T
Bottom Bracket
(MID MOTOR) SHIMANO DRIVE UNIT DU-E5000
Chain
KMC X10E
Pedals
FLAT ALLOY PEDAL
Wheels
Rims
ALLOY DOUBLE WALL RIMS WITH ALLOY HUB (TUBELESS READY)
Tires
SCHWALBE SUPER MOTO-X 27.5”X2.40
Brakes
Brakes
Hydraulic Disc
Brake Levers
SHIMANO BR-MT201
Cockpit
Handlebar
ENTITY XPERT, ALLOY, 700MM
Headset
ZS 44/28.6 | ZS 56/40
Seat
Saddle
ENTITY SADDLE, STEEL RAIL
Seatpost
ENTITY XPERT, ALLOY, 27.2X300MM
Motor & Battery
Battery
SHIMANO BT-E8010, 504W h
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.49 mm | 1.52 mm |
| Bottom Bracket Height | 287 mm | 287 mm | 287 mm |
| Front Center | 616 mm | 631 mm | 650 |
| Rake | 50 mm | 50 mm | 50 mm |
| Trail | 61 mm | 58 mm | 58 mm |
| Stack | 553 mm | 584 mm | 612 mm |
| Reach | 382 mm | 392 mm | 402 mm |
| Top Tube Length | 556 mm | 562 mm | 586 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 460 mm | 490 mm | 520 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 140 mm | 170 mm | 200 mm |
| Chainstay Length | 452 mm | 452 mm | 452 mm |
| Wheelbase | 1059 mm | 1074 mm | 1093 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm |
| Standover Height | 696 mm | 728 mm | 758 mm |
| Wheels | 650 | 650 | 650 |
| Rider Min Height | 160 cm | 169 cm | 179 cm |
| Rider Max Height | 171 cm | 181 cm | 190 cm |
About this model
PATH E5 GENT is part of the Polygon Path model. Polygon released 30 bikes variations of this model so far. Take a sneak peek at all Polygon Path bikes models from 2023, by clicking here.
Model range prices
Polygon PATH 2 2023 is the most economical model, with a starting price of 559$. Polygon PATH E5 LADY 2023 on the other hand costs 2249$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Commuter bikes
According to our calculations, the average cost of a Commuter bike that is reliable is 762$. However, even if your budget is less than the average, you might still be able to get a top-quality Commuter bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Commuter bikes
If we make a quick analysis of the average weight of a Commuter bike, we get 14.29 kg (31.5 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Polygon PATH E5 GENT it’s weighing 19.9 kg (43.87 lbs). At this weight, is much heavier than average. To sum up, it’s 39.26% heavier than the average weight of Commuter bikes.
PATH E5 GENT components
Fork material
PATH E5 GENT has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
The wheels on PATH E5 GENT are the aluminum type. After 700c wheels, 650b is the second most popular choice for road bikes. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 160 cm – 190 cm (5.25 ft – 6.23 ft). In short, it won’t be difficult to find the right one for you.
