Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
150cm - 164cm
MD
162cm - 176cm
LG
174cm - 189cm
XL
187cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
aluminum
Suspension Fork
CARBON RIGID
Drivetrain
Rear Derailleur
SHIMANO TIAGRA 10 SPEED
Shift Levers
SHIMANO TIAGRA RAPID FIRE 10 SPEED
Cassette
SHIMANO CS HG500-10
Crank
PROWHEEL 48T
Bottom Bracket
PROWHEEL BB 68mm
Chain
KMC X10 FOR 10-SPEED
Pedals
ONE PIECE PP FLAT
Wheels
Front Hub
F: ALLOY DISC BRAKE 12x100mm 24H / R: ALLOY DISC BRAKE 12x142mm 32H CL FOR SPROCKET
Rear Hub
F: ALLOY DISC BRAKE 12x100mm 24H / R: ALLOY DISC BRAKE 12x142mm 32H CL FOR SPROCKET
Rims
ALLOY DOUBLE WALL FV H: 30 622X19 24H FOR TYRE 622-28/62 DISC
Spokes
F: STAINLESS 14G NDS:276 & DS:280 / R: STAINLESS 14G NDS:278 & DS:278
Tires
VEE G-SPORT 700x35C 622x35
Brakes
Brakes
TEKTRO HD-M275 HYDRAULIC DICS
Brake Levers
TEKTRO HD-M275
Cockpit
Handlebar
ALLOY, W: 680mm, BB: 31,8mm, R/D: 0mm, B: 6 degree
Headset
FSA NO. 42 W/ SEALED BEARING
Seat
Saddle
POLYGON SADDLE
Seatpost
ALLOY SEATPOST, DXL: 27,2 x 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.47 mm | 1.5 mm | 1.54 mm |
| Bottom Bracket Height | 286 mm | 286 mm | 286 mm | 286 mm |
| Front Center | 604 mm | 623 mm | 639 mm | 658 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 71 mm | 71 mm | 67 mm | 67 mm |
| Stack | 537.24 mm | 565.52 mm | 595.87 mm | 624.23 mm |
| Reach | 376 mm | 386 mm | 396 mm | 406 mm |
| Top Tube Length | 526.1 mm | 543.94 mm | 568.01 mm | 592.09 mm |
| Seat Tube Angle | 74.5 ° | 73.5 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 430 mm | 460 mm | 490 mm | 520 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71 ° |
| Head Tube Length | 115 mm | 145 mm | 175 mm | 205 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1029 mm | 1049 mm | 1064 mm | 1084 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 699 mm | 730 mm | 759 mm | 788 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 150 cm | 162 cm | 174 cm | 187 cm |
| Rider Max Height | 164 cm | 176 cm | 189 cm | 195 cm |
About this model
PATH F4 belongs to the Polygon Path model. Polygon launched 30 bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Polygon PATH 2 2023 is the most economical model, with a starting price of 559$. Polygon PATH E5 LADY 2023 on the other hand costs 2249$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Fitness bikes
According to our calculations, the average cost of a Fitness bike that is reliable is 656$. However, even if your budget is less than the average, you might still be able to get a top-quality Fitness bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 849$. In conclusion, this bike price is 29.42% more expensive than the price of the average Fitness bike.
Overview of components
Fork material
PATH F4 has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
The PATH F4 2023 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The PATH F4 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 150 cm – 195 cm (4.92 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
