Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" / 29" -
Travel Front 120mm -
Fork SunTour XCR 32
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 165cm
MD
162cm - 175cm
MD
162cm - 175cm
LG
172cm - 185cm
LG
172cm - 185cm
XL
182cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALX XC 27.5” & 29”
Suspension Fork
SUNTOUR XCR 32 LO-R, 120MM (27.5”) / 120MM (29”) TRAVEL
Rear Shock
-
Drivetrain
Rear Derailleur
SHIMANO, DEORE RD-M5100 11-SPEED
Shift Levers
SHIMANO DEORE SL-M5100 11-SPEED
Cassette
SHIMANO, DEORE CS-M5100 11-51T 11-SPEED
Crank
SHIMANO, DEORE FC-MT510-0 32T 11/10-SPEED
Bottom Bracket
BSA THREADED
Chain
KMC X-11 11-SPEED
Wheels
Rims
DOUBLE WALL ALLOY RIMS
Tires
SPYDERBAIT SA-290 27.5”X2.25” / 29”X2.25”
Brakes
Brakes
SHIMANO BR-M201 HYDRAULIC DISC BRAKE
Cockpit
Stem
ENTITY SPORT, ALLOY E:45MM BB:31.8MM
Handlebar
ENTITY SPORT, ALLOY W:760MM R:12MM BB:31.8MM
Seat
Saddle
ENTITY VOID
Seatpost
ENTITY SPORT, 15MM OFFSET, 27.2MMX350MM
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD | LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.39 mm | 1.46 mm | 1.34 mm | 1.41 mm | 1.36 mm |
| Bottom Bracket Height | 310 mm | 310 mm | 309 mm | 310 mm | 309 mm | 309 mm |
| Front Center | 685 mm | 707 mm | 720 mm | 729 mm | 742 mm | 764 mm |
| Rake | 37 mm | 37 mm | 44 mm | 37 mm | 44 mm | 44 mm |
| Trail | 111 mm | 111 mm | 111 mm | 111 mm | 111 mm | 111 mm |
| Stack | 595.8 mm | 601.3 mm | 631.3 mm | 605 mm | 635.2 mm | 639.8 mm |
| Reach | 412 mm | 432 mm | 432 mm | 452 mm | 452 mm | 472 mm |
| Top Tube Length | 571 mm | 592 mm | 600 mm | 614 mm | 621 mm | 642 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 385 mm | 425 mm | 425 mm | 460 mm | 460 mm | 500 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 95 mm | 100 mm | 95 mm | 105 mm | 100 mm | 105 mm |
| Chainstay Length | 427 mm | 427 mm | 437 mm | 427 mm | 437 mm | 437 mm |
| Wheelbase | 1108 mm | 1130 mm | 1149 mm | 1152 mm | 1171 mm | 1193 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 65 mm | 45 mm | 65 mm | 65 mm |
| Standover Height | 665 mm | 699 mm | 695 mm | 728 mm | 717 mm | 753 mm |
| Wheels | 27" | 27" | 29" | 27" | 29" | 29" |
| Rider Min Height | 152 cm | 162 cm | 162 cm | 172 cm | 172 cm | 182 cm |
| Rider Max Height | 165 cm | 175 cm | 175 cm | 185 cm | 185 cm | 195 cm |
About this model
XTRADA 6 1×11 completes the Polygon Xtrada model. 32 bikes variations carry this model name so far. Check out the entire range from 2020 of this model, by clicking this link.
Model range prices
Polygon XTRADA 5 2020 is the cheapest bike model and costs 799$. Polygon XTRADA 8 2020 is the most expensive one and costs 1199$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 899$. Doing a quick comparison, we notice that XTRADA 6 1×11 price is 207.23% lower than the average cost of a Trail bike.
XTRADA 6 1×11 components
Fork
This bike has the SunTour XCR 32 fork installed. The fork’s travel is 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
As for the wheels, Polygon XTRADA 6 1×11 2020, has a 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Polygon XTRADA 6 1×11 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
There are 6 sizes available for this model. Rider height can be anywhere between 152 cm – 195 cm (4.99 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
