Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Suspension Rigid -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
700c, Twin Top Tube Frame, Steel
Suspension Fork
Steel with Die Cast Drop Outs
Drivetrain
Cassette
Alloy, 42 tooth
Crank
Forged Alloy, Three Piece with Guard
Bottom Bracket
Sealed Cartridge
Chain
KMC Z410
Pedals
PC Platform
Wheels
Front Hub
Alloy, 32 Hole, Nutted
Rear Hub
Alloy Track Hub, Fixed/Free, 32 Hole, Nutted
Rims
Alloy, 40mm High Profile, CNC Brake Surface
Spokes
Black, 14g
Tires
Kenda K193, 700 x 32c
Brakes
Brakes
Promax, Alloy Dual Pivot
Brake Levers
Promax BL-42, Alloy
Cockpit
Stem
Integrated with Handlebar, 7 Degree Rise
Handlebar
Alloy, Urban One Piece Bar and Stem, 620mm Wide, 12 Degree Sweep
Grips
Flangeless, Lock-On Comfort Grip, 135mm
Headset
Sealed, 1-1/8"
Seat
Saddle
Classic Road with Rivets
Seatpost
Alloy, Micro Adjust, 27.2 x 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.42 mm | 1.41 mm | 1.39 mm |
| Front Center | 572 mm | 597 mm | 617 mm | 643 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 54 mm | 54 mm | 55 mm | 54 mm |
| Stack | 536 mm | 555 mm | 574 mm | 593 mm |
| Reach | 373 mm | 392 mm | 407 mm | 426 mm |
| Top Tube Length | 526 mm | 551 mm | 571 mm | 596 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 520 mm | 550 mm | 580 mm | 600 mm |
| Head Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 100 mm | 120 mm | 140 mm | 160 mm |
| Chainstay Length | 451 mm | 451 mm | 451 mm | 451 mm |
| Wheelbase | 1016 mm | 1041 mm | 1061 mm | 1087 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 774 mm | 800 mm | 826 mm | 846 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Carlton completes the Raleigh Carlton model. Raleigh launched 8 bikes of this model so far. Take a sneak peek at all Raleigh Carlton bikes models from 2018, by clicking here.
Model range prices
The most economical model, the Raleigh CARLTON MIXTE 2018 has a starting price of 499$. Raleigh Carlton Mixte 8 2018 on the other hand is the most expensive at 549$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Commuter bikes
If you want an acceptable Commuter bike you should know that the average price is 762$. However, this doesn’t mean that if you spend less money on a Commuter bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2018 for 499$. If we compare this with the average Commuter bike cost we notice that the price is 52.71% smaller.
Carlton components
Fork material
The fork is made out of steel, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels size
The wheels on Carlton are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
Sizes
Carlton comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
