Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Acera, Altus -
Suspension Rigid -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
700c, Twin Top Tube Frame, Steel
Suspension Fork
Steel with Die Cast Drop Outs
Drivetrain
Rear Derailleur
Shimano Acera
Shift Levers
Shimano 8 Speed, SL-M310 Right Only
Cassette
Alloy, 42 tooth
Crank
Forged Alloy, Three Piece, 104BCD with Guard
Bottom Bracket
Sealed Cartridge
Chain
KMC Z50
Pedals
Alloy Platform
Wheels
Front Hub
Alloy, 32 Hole, Nutted
Rear Hub
Alloy, 32 Hole, Nutted
Spokes
Black, 14g
Tires
Kenda K193, 700 x 32c
Brakes
Brakes
Promax, Alloy Dual Pivot
Brake Levers
Promax BL-42, Alloy
Cockpit
Stem
Integrated with Handlebar, 7 Degree Rise
Handlebar
Alloy, Urban One Piece Bar and Stem, 620mm Wide, 12 Degree Sweep
Grips
Flangeless, Lock-On Comfort Grip, 135mm
Headset
Sealed, 1-1/8"
Seat
Saddle
Classic Road with Rivets
Seatpost
Alloy, Micro Adjust, 27.2 x 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.42 mm | 1.41 mm | 1.39 mm |
| Front Center | 572 mm | 597 mm | 617 mm | 643 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 54 mm | 54 mm | 55 mm | 54 mm |
| Stack | 536 mm | 555 mm | 574 mm | 593 mm |
| Reach | 373 mm | 392 mm | 407 mm | 426 mm |
| Top Tube Length | 526 mm | 551 mm | 571 mm | 596 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 520 mm | 550 mm | 580 mm | 600 mm |
| Head Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 100 mm | 120 mm | 140 mm | 160 mm |
| Chainstay Length | 451 mm | 451 mm | 451 mm | 451 mm |
| Wheelbase | 1016 mm | 1041 mm | 1061 mm | 1087 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 774 mm | 800 mm | 826 mm | 846 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Carlton 8 is part of the Raleigh Carlton model. Raleigh launched 8 bikes of this model so far. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
The most economical model, the Raleigh CARLTON MIXTE 2018 has a starting price of 499$. Raleigh Carlton Mixte 8 2018 on the other hand is the most expensive at 549$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Commuter bikes
If you want to purchase a solid Commuter bike, it is important to know that the average cost is 762$. However, this doesn’t mean that if you spend less money on a Commuter bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Raleigh released this model in 2018, its price was 549$. In conclusion, this bike price is 38.8% smaller than the price of the average Commuter bike.
Overview of components
Fork material
The fork is made out of steel, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels
When leaving the production line, the Carlton 8 model has 700c wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Carlton 8 has Rim brakes. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
Carlton 8 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
