Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Altus, Tourney -
Suspension Rigid -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Custom Formed AL-6061 Heat Treated Aluminum 700c True Comfort Frame
Suspension Fork
Steel Hybrid with Fender Mounts
Drivetrain
Rear Derailleur
Shimano Altus M310
Front Derailleur
Shimano Tourney TY510
Shift Levers
Shimano ST-EF500 EZ Fire Plus Trigger Shifter
Cassette
Shimano MF-TZ500 7spd Freewheel (14-34t)
Crank
Suntour XCC-T208 with Alloy Arms and 28/38/48t Steel Rings, With Chainguard
Bottom Bracket
Sealed Cartridge bearing
Chain
KMC Z-7
Pedals
Raleigh PP Urban with Traction Tape
Wheels
Front Hub
Formula Alloy Quick Release, 32-hole
Rear Hub
Formula Alloy Freewheel, Quick Release, 32-hole
Rims
Alloy, Double Wall
Spokes
14g Stainless Steel
Tires
Vee Tire Co. Easy Street, 700x42c
Brakes
Brakes
Tektro 837 Alloy V-Brake
Brake Levers
Shimano, Alloy 4-finger
Cockpit
Stem
Alloy Quill
Handlebar
Alloy City Comfort Bar
Grips
Raleigh Comfort
Headset
Semi-Integrated Threaded 1-1/8"
Seat
Saddle
Raleigh Comfort
Seatpost
Alloy Micro Adjust 27.2x300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.422 mm | 1.474 mm | 1.521 mm | 1.567 mm |
| Front Center | 628 mm | 644 mm | 660 mm | 676 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 74 mm | 74 mm | 74 mm | 75 mm |
| Stack | 559 mm | 588 mm | 616 mm | 644 mm |
| Reach | 393 mm | 399 mm | 405 mm | 411 mm |
| Top Tube Length | 575 mm | 590 mm | 605 mm | 620 mm |
| Seat Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 400 mm | 450 mm | 500 mm | 550 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 130 mm | 160 mm | 190 mm | 220 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1074 mm | 1090 mm | 1106 mm | 1122 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 717 mm | 761 mm | 803 mm | 846 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Detour 1 is part of the Raleigh Detour model. There are 25 bikes that carry this model name. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
Raleigh Detour 1 2019 is the cheapest bike model and costs 399$. Raleigh Detour 3 2019 is the most expensive one and costs 599$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Comfort bikes
If you want to purchase a solid Comfort bike, it is important to know that the average cost is 360$. However, even if your budget is less than the average, you might still be able to get a top-quality Comfort bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Raleigh Detour 1 price was 399$. If we compare this with the average Comfort bike cost we notice that the price is 10.83% higher.
Detour 1 components
Fork material
When it comes to the fork, this bike has a steel one, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels
The wheels on Detour 1 are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
Detour 1 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
