Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Direct Connect High Modulus Carbon, Tapered Headtube, Thru-Axles and CDS Internal Cable Routing
Suspension Fork
Full Carbon Monocoque 1-1/8" to 1.5" Taper, Thru-Axle with Post Disc Mounts
Drivetrain
Rear Derailleur
Shimano Ultegra
Front Derailleur
Shimano Ultegra
Shift Levers
Shimano Ultegra 11spd STI, Jagwire Housing w/Stainless Cables
Cassette
Shimano 105 11spd (11-32t)
Crank
Shimano Ultegra Compact 34/50t
Bottom Bracket
Shimano External Bearing
Chain
Shimano HG600 11spd
Pedals
Test Ride Pedals
Wheels
Front Hub
Novatec Alloy Disc, 15mm, 32H, Thru-Axle, Sealed Bearings
Rear Hub
Novatec Alloy disc, 142x12mm, Thru-Axle, Sealed Bearing, Cassette
Rims
Weinmann Aquila 19, Double Wall 23mm Wide
Spokes
Double Butted Stainless 14/15g MAC
Tires
Clement Strada LGG 60TPI, 700x28c
Brakes
Brakes
Shimano Ultegra Hydraulic
Brake Levers
Shimano Ultegra STI
Cockpit
Stem
3D Forged Anti-Shock, 31.8, 90/100/110mm
Handlebar
Raleigh 200 Series Aero Ergo Flat Top Road, 31.8 with 10 Degree Flare, 40/42/44cm
Headset
Integrated Cartridge Bearings
Seat
Saddle
Raleigh 200 series Saddle
Seatpost
Anti-Shock 27.2x300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 52cm | 54cm | 56cm | 58cm | 60cm | 62cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.5 mm | 1.5 mm | 1.51 mm | 1.52 mm | 1.52 mm |
| Bottom Bracket Height | 258 mm | 261 mm | 261 mm | 263 mm | 263 mm | 263 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Stack | 547 mm | 567 mm | 583 mm | 599 mm | 614 mm | 629 mm |
| Reach | 375 mm | 378 mm | 388 mm | 396 mm | 403 mm | 413 mm |
| Top Tube Length | 540 mm | 550 mm | 565 mm | 580 mm | 595 mm | 610 mm |
| Seat Tube Angle | 73 ° | 74 ° | 73.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 490 mm | 510 mm | 530 mm | 550 mm | 570 mm | 590 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 140 mm | 160 mm | 175 mm | 195 mm | 210 mm | 225 mm |
| Chainstay Length | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm |
| Bottom Bracket Drop | 77 mm | 75 mm | 75 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 765 mm | 785 mm | 805 mm | 825 mm | 840 mm | 860 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Merit Elite completes the Raleigh Merit model. Raleigh released 8 bikes variations of this model so far. Take a sneak peek at all Raleigh Merit bikes models from 2017, by clicking here.
Model range prices
The most economical model, the Raleigh Merit 1 2017 has a starting price of 849$. Raleigh Merit Elite 2017 on the other hand is the most expensive at 2599$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Endurance bikes average price
If you want an acceptable Endurance bike you should know that the average price is 2346$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Endurance bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Raleigh released this model in 2017, its price was 2599$. Comparing the average cost of an Endurance bike to this one, you will see that Merit Elite price is 10.78% more expensive.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork material
Merit Elite has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
The Merit Elite 2017 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Raleigh Merit Elite is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
