Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 80mm -
Fork SunTour
-
Groupset Altus, Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Custom Formed Butted Alloy Tubing
Suspension Fork
SR Suntour, 80mm Travel
Drivetrain
Rear Derailleur
Shimano Altus RD-M130
Front Derailleur
Shimano Tourney FD-TY510
Shift Levers
SHIMANO ST-EF500, 7spd
Cassette
Shimano 7spd (12-32t)
Crank
SR Suntour 28/38/48t w/Chainguard
Bottom Bracket
Sealed Cartridge
Chain
KMC Z7
Pedals
Alloy Body/Steel Cage
Wheels
Front Hub
Formula Alloy Disc QR 32h
Rear Hub
Formula Alloy Disc QR 32h
Rims
Alloy, DDM-1 Double Wall Disc
Spokes
14g Stainless Steel
Tires
Vee Zilent, 700x47c
Brakes
Brake Levers
Tektro
Cockpit
Stem
Alloy, 7 deg Rise, 31.8 Bore
Handlebar
Alloy, 15mm Rise, 9 deg Back, 31.8
Grips
Raleigh Comfort
Headset
Semi Integrated 1-1/8"
Seat
Saddle
Raleigh Series w/ Steel Rail
Seatpost
Alloy Micro Adjust 27.2x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | LG | SM | MD | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 0.68 mm | 0.67 mm | 0.67 mm | 0.68 mm |
| Front Center | 653 mm | 611 mm | 629 mm | 669 mm |
| Rake | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 194 mm | 191 mm | 197 mm | 200 mm |
| Stack | 403 mm | 371 mm | 384 mm | 412 mm |
| Reach | 590 mm | 557 mm | 574 mm | 609 mm |
| Top Tube Length | 531 mm | 546 mm | 561 mm | 601 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 595 mm | 460 mm | 500 mm | 580 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 170 mm | 130 mm | 150 mm | 190 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1075 mm | 1031 mm | 1050 mm | 1091 mm |
| Bottom Bracket Drop | 70 mm | 75 mm | 70 mm | 70 mm |
| Standover Height | 811 mm | 751 mm | 776 mm | 836 mm |
| Wheels | 700 | 700 | 700 | 700 |
About this model
Route 1 is a Raleigh Route model. Raleigh released 8 bikes variations of this model so far. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
Raleigh Route 1 2018 is the cheapest bike model and costs 499$. Raleigh Route 2 2018 is the most expensive one and costs 599$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Hybrid bikes average price
According to our calculations, the average cost of a Hybrid bike that is reliable is 562$. However, you could also get a good Hybrid bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2018 for 499$. If we compare this with the average Hybrid bike cost we notice that the price is 12.63% lower.
Overview of components
Fork
This bike has the SunTour fork installed. The fork’s travel is 80mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
The wheels on Route 1 are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
