Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 75mm -
Fork SunTour
-
Groupset Acera, Altus -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alloy, Custom Formed and Butted Tubing
Suspension Fork
SR Suntour SF15-NVX, Lock-Out, 75mm Travel
Drivetrain
Rear Derailleur
Shimano Acera, 8sp
Front Derailleur
Shimano Altus
Shift Levers
Shimano SL-M310, 8sp
Cassette
Shimano 8spd (11-32t)
Crank
Shimano Altus, 28/38/48t
Bottom Bracket
Sealed Cartridge
Chain
KMC Z8
Pedals
Alloy Body/Alloy Cage/Chromo Spindle
Wheels
Front Hub
Formula Alloy Disc QR 32h
Rear Hub
Formula Alloy Disc QR 32h
Rims
Alloy, DDM-1 Double Wall Disc
Spokes
14g Stainless Steel
Tires
Vee Zilent, 700x47c
Brakes
Brakes
Tektro Airies Mechanical Disc w/160mm Rotors
Brake Levers
Tektro
Cockpit
Stem
Alloy, 7 deg Rise, 31.8 Bore
Handlebar
Alloy, 15mm Rise, 9 deg Back, 31.8
Grips
Raleigh Comfort
Headset
Semi Integrated 1-1/8"
Seat
Saddle
Raleigh Series w/ Steel Rail
Seatpost
Alloy Micro Adjust 27.2x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 0.67 mm | 0.67 mm | 0.68 mm | 0.68 mm |
| Front Center | 611 mm | 629 mm | 653 mm | 669 mm |
| Rake | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 191 mm | 197 mm | 194 mm | 200 mm |
| Stack | 372 mm | 385 mm | 404 mm | 413 mm |
| Reach | 558 mm | 575 mm | 591 mm | 610 mm |
| Top Tube Length | 547 mm | 562 mm | 587 mm | 602 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 460 mm | 500 mm | 540 mm | 580 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 130 mm | 150 mm | 170 mm | 190 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1032 mm | 1051 mm | 1076 mm | 1092 mm |
| Bottom Bracket Drop | 75 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 752 mm | 777 mm | 812 mm | 837 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Route 2 completes the Raleigh Route model. 8 bikes variations carry this model name so far. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
Raleigh Route 1 Step Thru 2019 is the most affordable bike of this model and has a price of 499$. On the other hand, Raleigh Route 3 2019, is the most expensive and costs 749$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Hybrid bikes
According to our calculations, the average cost of a Hybrid bike that is reliable is 562$. However, this doesn’t mean that if you spend less money on a Hybrid bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Raleigh released this model in 2019, its price was 599$. Doing a quick comparison, we notice that Route 2 price is 6.58% higher than the average cost of a Hybrid bike.
Overview of components
Fork
The SunTour is included from the factory. It has a travel distance of 75mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The wheels on Route 2 are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Raleigh Route 2 is equipped with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
