Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork SunTour XCM
-
Groupset Acera, Shimano -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL-6061 SL Custom Butted Aluminum, IS Disc Mount, Machined HT 1-1/8"
Suspension Fork
SR Suntour XCM, 120mm
Drivetrain
Rear Derailleur
Shimano Acera 8spd
Front Derailleur
Shimano
Shift Levers
Shimano EZ-Fire
Cassette
Shimano HG41, 11-32t 8spd
Crank
SR Suntour XCC 42/34/24t
Bottom Bracket
Sealed Cartridge, 73x122
Chain
KMC Z51
Pedals
Test Ride Pedals
Wheels
Front Hub
Joytech Disc QR 32h
Rear Hub
Joytech Disc QR 32h Cassette
Rims
Weinmann U28, 27.5", 32h, 28mm wide
Spokes
14g Stainless Steel, w/ Brass Nipples
Tires
Kenda Honey Badger 27.5 x 2.2
Brakes
Brakes
Tektro Hydraulic Disc, 160mm rotors
Brake Levers
Tektro
Cockpit
Stem
Raleigh 100 Series, 31.8mm, Lengths:60mm
Handlebar
Raleigh MTB Riser, 31.8, Width:S 720mm, 740mm other sizes
Grips
Raleigh Closed-end MTB Grip
Headset
FSA IS-3 45deg upper, NO.11N Zerostack Lower, 1-1/8"
Seat
Saddle
Raleigh Mountain Saddle, 140mm wide
Seatpost
Raleigh 100 Series, Dual Bolt, 30.9x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Top Tube Length | 562 mm | 582 mm | 607 mm | 627 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 380 mm | 430 mm | 480 mm | 530 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 105 mm | 110 mm | 130 mm | 150 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1065 mm | 1086 mm | 1102 mm | 1124 mm |
| Standover Height | 742 mm | 742 mm | 742 mm | 767 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Tokul 1 is a Raleigh Tokul model. Raleigh launched 11 bikes of this model so far. You can get a glimpse at all models from 2017, by clicking on this link.
Model range prices
Raleigh Tokul 24 2017 is the most economical model, with a starting price of 329$. Raleigh Tokul 4130 2017 on the other hand costs 1599$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Raleigh released this model in 2017, its price was 499$. Doing a quick comparison, we notice that Tokul 1 price is 453.51% lower than the average cost of a Trail bike.
Tokul 1 components
Fork
The fork installed on this bike is the SunTour XCM model. The travel on this model is 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The Tokul 1 2017 bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Raleigh Tokul 1 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
