Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 650b -
Groupset Tourney, Shimano -
Suspension Rigid -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
27.5 Steel, Raleigh "True Comfort" Geometry
Suspension Fork
Steel Threaded
Drivetrain
Rear Derailleur
Shimano TX-35
Shift Levers
Shimano Revo 7spd
Cassette
40t w/Double Guard
Crank
170mm Alloy
Bottom Bracket
Cartridge BB
Chain
KMC Z51
Pedals
Raleigh Comfort Platform
Wheels
Front Hub
Alloy QR 32h
Rear Hub
Alloy QR 32h
Rims
Weinmann XR28
Spokes
14g Stainless Steel
Tires
Kenda 27.5x1.95
Brakes
Brakes
Alloy V-Brake
Brake Levers
Alloy V-Brake
Cockpit
Stem
Alloy Quill 25.4, 80mm Extension, 30 Deg Rise
Handlebar
Steel Comfort Riser
Grips
Raleigh Comfort Grip
Headset
Threaded 1-1/8"
Seat
Saddle
Raleigh Comfort
Seatpost
Alloy 28.6x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.61 mm | 1.66 mm | 1.71 mm | 1.76 mm |
| Front Center | 604 mm | 619 mm | 635 mm | 650 |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm |
| Trail | 71 mm | 71 mm | 70 mm | 71 mm |
| Stack | 599 mm | 627 mm | 655 mm | 684 mm |
| Reach | 372 mm | 377 mm | 383 mm | 389 mm |
| Top Tube Length | 567 mm | 582 mm | 597 mm | 612 mm |
| Seat Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 380 mm | 430 mm | 480 mm | 530 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 150 mm | 180 mm | 210 mm | 240 mm |
| Chainstay Length | 452 mm | 452 mm | 452 mm | 452 mm |
| Wheelbase | 1047 mm | 1062 mm | 1078 mm | 1093 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 732 mm | 777 mm | 812 mm | 852 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Venture is a Raleigh Venture model. Raleigh launched 12 bikes of this model so far. Take a sneak peek at all Raleigh Venture bikes models from 2017, by clicking here.
Model range prices
Raleigh Venture 2017 is the most affordable bike of this model and has a price of 299$. On the other hand, Raleigh Venture 4.0 Step Thru 2017, is the most expensive and costs 449$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Comfort bikes
If you want to purchase a solid Comfort bike, it is important to know that the average cost is 360$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Comfort bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Raleigh released this model in 2017, its price was 299$. Comparing this to the average Comfort bike price, we see that the price is 20.4% smaller.
Overview of components
Fork material
Venture has a steel fork, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels
As for the wheels, Raleigh Venture 2017, has a aluminum model. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
Nothing is more important on a bike than its ability to brake properly. Raleigh Venture is equipped with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
Sizes
Venture comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
