Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Apex 1, Praxis -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL-6061 Alloy Gravel, Thru-Axle, Disc Tabs, Taper HT
Suspension Fork
Carbon/Alloy Tapered Steerer, Thru-Axle, Disc Post Mount
Drivetrain
Rear Derailleur
SRAM Apex 1, 11 Speed
Shift Levers
SRAM Apex 1, 11 Speed
Cassette
SRAM PG1130, 11 Speed,11-42
Crank
Praxis Works Alba M30, 38 Tooth Direct Mount
Bottom Bracket
Praxis Works M30 External Bearings
Chain
KMC X11-1 EPT Anti-Rust
Pedals
Resin Platform Pedal
Wheels
Front Hub
Alloy Disc, Cartridge Bearing, 15mm Thru Axle, 28 Hole
Rear Hub
Alloy Disc, Cartridge Bearing, Thru Axle, 28 Hole
Rims
HED Tomcat Disc, 28 Hole, Tubless Compatible
Spokes
14g Stainless with Brass Nipples
Tires
Clement X'PLOR MSO, 700x40c, 60TPI
Brakes
Brakes
TRP Spyre Mechanical Disc, 160mm Rotors
Brake Levers
SRAM Apex
Cockpit
Stem
HED Eroica, 31.8, Lengths:/90/100/110/mm
Handlebar
HED Eroica, 31.8 with 16 Degree Flare, 38/40/42/44/46
Headset
Integrated Cartridge Bearings
Seat
Saddle
Raleigh Series Saddle with Chromo Rail
Seatpost
HED Eroica, 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 52cm | 54cm | 56cm | 58cm | 60cm | 62cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.51 mm | 1.51 mm | 1.56 mm | 1.56 mm | 1.56 mm |
| Bottom Bracket Height | 274 mm | 274 mm | 274 mm | 276 mm | 276 mm | 276 mm |
| Front Center | 598 mm | 598 mm | 614 mm | 619 mm | 634 mm | 650 |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 68 mm | 67 mm | 67 mm | 64 mm | 64 mm | 64 mm |
| Stack | 554 mm | 571 mm | 585 mm | 608 mm | 622 mm | 641 mm |
| Reach | 383 mm | 377 mm | 388 mm | 390 mm | 400 mm | 410 mm |
| Top Tube Length | 535 mm | 550 mm | 565 mm | 580 mm | 595 mm | 610 mm |
| Seat Tube Angle | 74.3 ° | 73 ° | 73 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 490 mm | 510 mm | 530 mm | 550 mm | 570 mm | 590 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 120 mm | 140 mm | 155 mm | 180 mm | 195 mm | 215 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1032 mm | 1032 mm | 1048 mm | 1054 mm | 1069 mm | 1085 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 775 mm | 795 mm | 810 mm | 830 mm | 850 mm | 870 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Willard 3 belongs to the Raleigh Willard model. 12 bikes variations carry this model name so far. You can easily view all of the Raleigh Willard bikes models from 2018, here.
Model range prices
Raleigh Willard 1 2018 is the cheapest bike model and costs 849$. Raleigh Willard 3 2018 is the most expensive one and costs 1399$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Raleigh released this model in 2018, its price was 1399$. Comparing this to the average Gravel bike price, we see that the price is 75.98% smaller.
Overview of components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The wheels on Willard 3 are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Raleigh Willard 3 is equipped with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
