Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Rival 1, Rival 22 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Revel Gravel Fork 12×100 47mm
Drivetrain
Rear Derailleur
SRAM Rival 1 Long Cage 11spd
Shift Levers
SRAM Rival 22 11spd
Cassette
SRAM 11-42t Black
Crank
SRAM Rival 1 175mm 42T or 172.5mm 40T/42T
Bottom Bracket
BSA 68mm English Threaded
Chain
SRAM 11spd
Wheels
Rims
Industry Nine 700c 1/1 GRCX Centerlock (*upgrade available)
Tires
Maxxis Rambler 700x40c
Brakes
Brakes
SRAM Rival 1 Hydro
Disk Rotors
SRAM Centerline Rotor 160mm Centerlock
Cockpit
Stem
Zipp Service Course SL 80 or 90mm
Handlebar
Zipp Service Course SL 70 XPLR 44cm
Grips
Lizard Skins Tape 2.5mm Black
Headset
IS42 Upper / IS52 Lower
Seat
Saddle
WTB Volt CroMo Black
Seatpost
Revel Carbon Seatpost 27.2 x 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.38 mm | 1.4 mm | 1.42 mm | 1.44 mm |
| Bottom Bracket Height | 288 mm | 288 mm | 288 mm | 288 mm | 288 mm |
| Front Center | 606 mm | 624 mm | 639 mm | 654 mm | 672 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Stack | 534 mm | 559 mm | 579 mm | 599 mm | 624 mm |
| Reach | 396 mm | 406 mm | 414 mm | 422 mm | 432 mm |
| Top Tube Length | 539 mm | 556 mm | 569 mm | 582 mm | 599 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 450 mm | 490 mm | 520 mm | 550 mm | 580 mm |
| Head Tube Angle | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 110 mm | 136 mm | 157 mm | 178 mm | 205 mm |
| Chainstay Length | 419 mm | 419 mm | 419 mm | 419 mm | 419 mm |
| Wheelbase | 1015 mm | 1033 mm | 1048 mm | 1063 mm | 1081 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Rover – Sram Rival belongs to the Revel Rover model. Revel released 16 bikes variations of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Revel Rover – Sram Rival 2022 is the cheapest bike model and costs 3999$. Revel Rover SRAM RED AXS KIT 2022 is the most expensive one and costs 8199$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Revel Rover – Sram Rival price was 3999$. Comparing the average cost of a Gravel bike to this one, you will see that Rover – Sram Rival price is 62.43% higher.
Rover – Sram Rival components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
The Rover – Sram Rival 2022 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Revel Rover – Sram Rival is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
