Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
158cm - 166cm
SM
164cm - 171cm
MD
169cm - 178cm
LG
175cm - 183cm
XL
180cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 T6 Heat Treated Aluminium.
Suspension Fork
CX AL, Full Carbon Fibre Monocoque.
Drivetrain
Rear Derailleur
Shimano105 R7000 Medium Cage.
Front Derailleur
Shimano 105 R7000 Braze-On.
Shift Levers
Shimano 105 R7020 Hydraulic 11 Speed.
Cassette
Shimano 105 R7000 11 Speed 11-28T.
Crank
Shimano 105 R7000 11-Speed, 50- 34T.
Bottom Bracket
Shimano BB-R60 BSA.
Chain
Shimano HG601 11 Speed.
Wheels
Rims
Mavic Aksium Disc, 12x100mm Front, 12x142mm Rear.
Tires
Challenge Grifo Comp Rigid 700x33c, Black.
Brakes
Brakes
Shimano 105 BR-R7070 Flat Mount Hydraulic Disc.
Disk Rotors
Tektro Centrelock 160mm.
Cockpit
Stem
LEVEL 1 6061 Alloy, Black.
Handlebar
LEVEL 1 6061 Alloy, Black.
Seat
Saddle
Prologo Kappa RS, Black.
Seatpost
LEVEL 1 6061 Alloy 27.2mm, 350mm, Black.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.43 mm | 1.46 mm | 1.5 mm | 1.53 mm |
| Bottom Bracket Height | 276 mm | 276 mm | 276 mm | 276 mm | 276 mm |
| Front Center | 588 mm | 589 mm | 595 mm | 605 mm | 612 mm |
| Rake | 45 mm | 43 mm | 44 mm | 44 mm | 45 mm |
| Trail | 71 mm | 69 mm | 65 mm | 65 mm | 62 mm |
| Stack | 535 mm | 552 mm | 568 mm | 587 mm | 607 mm |
| Reach | 383 mm | 385 mm | 389 mm | 392 mm | 396 mm |
| Top Tube Length | 525 mm | 540 mm | 550 mm | 570 mm | 585 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73.3 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 565 mm | 585 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72 ° | 72.3 ° |
| Head Tube Length | 110 mm | 125 mm | 140 mm | 160 mm | 180 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1009 mm | 1010 mm | 1016 mm | 1025 mm | 1033 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 164 cm | 169 cm | 175 cm | 180 cm |
| Rider Max Height | 166 cm | 171 cm | 178 cm | 183 cm | 188 cm |
Model Overview
CX, Shimano 105 completes the Ribble Cx model. 24 bikes variations carry this model name so far. Check out the entire range from 2021 of this model, by clicking this link.
Model range prices
The most economical model, the Ribble CX, Sram Apex 1x 2021 has a starting price of 1482$. Ribble CX SL – Pro Build, Ultegra Di2 2021 on the other hand is the most expensive at 4080$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Cyclocross bikes
According to our math, the average price for a trustworthy Cyclocross bike is 2012$. However, you could also get a good Cyclocross bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Ribble released this model in 2021, its price was 1977$. If we compare this with the average Cyclocross bike cost we notice that the price is 1.77% smaller.
CX, Shimano 105 components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
When leaving the production line, the CX, Shimano 105 model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The CX, Shimano 105 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Ribble CX, Shimano 105 bike has 5 sizes, in the range of 158 cm – 188 cm (5.18 ft – 6.17 ft). In short, you can easily find one that suits you.
