Rocky Mountain Element Carbon 30 2022
2022 Mountain
Estimate price |
4,259$
Weight | 13.59 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 130mm -
Travel Rear 120mm -
Fork Marzocchi Bomber Z2
-
Groupset SLX, FSA -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS Steep
142cm - 159cm
XS Slack
142cm - 159cm
SM Steep
156cm - 170cm
SM Slack
156cm - 170cm
MD Steep
167cm - 177cm
MD Slack
167cm - 177cm
LG Steep
175cm - 188cm
LG Slack
175cm - 188cm
XL Steep
185cm - 198cm
XL Slack
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SMOOTHWALL™ Carbon. Full Sealed Cartridge Bearings. Press Fit BB. Internal Cable Routing. RIDE-4™ Adjustable Geometry + Suspension Rate. 120mm Travel. SMOOTHWALL™ Carbon Rear Triangle
Suspension Fork
Marzocchi Z2 Float EVOL Rail 130mm | 44mm Offset
Rear Shock
Fox Float DPS Performance | Sealed Bearing Eyelet | 20x8mm F Hardware | All Sizes = 190x45mm | Size-Specific tune in FAQ
Drivetrain
Rear Derailleur
Shimano SLX
Shift Levers
Shimano SLX
Cassette
Shimano Deore 10-51T 12spd
Crank
FSA Comet MegaExo HD | 32T | 24mm Spindle | Crankarm Length: XS = 165mm | SM - XL = 170mm
Bottom Bracket
FSA BB92 24mm
Chain
Shimano M6100
Wheels
Front Hub
Shimano MT410 | 15mm Boost
Rear Hub
Shimano MT410 Boost 148mm
Rims
WTB ST Light i27 TCS 2.0 Tubeless | 28H | Tubeless Ready - Tape | Valves Incl
Spokes
2.0 Stainless
Tires
F: Maxxis Rekon 2.4 WT EXO Tubeless Ready | R: Maxxis Rekon 2.4 WT EXO Tubeless Ready |
Brakes
Brakes
Shimano MT4100 2 Piston | Resin Pads | F: Shimano RT30 180mm | R: Shimano RT30 180mm
Cockpit
Stem
Rocky Mountain 31.8 XC | 5° Rise | All Sizes = 50m
Handlebar
Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 31.8 Clamp
Grips
Rocky Mountain Lock On Light
Headset
FSA Orbit NO.57E | Sealed 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race
Seat
Saddle
WTB Volt 142
Seatpost
Rocky Mountain Toonie Drop Composite 30.9mm | XS - SM = 125mm | MD = 150mm | LG - XL = 170mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS Steep | XS Slack | SM Steep | SM Slack | MD Steep | MD Slack | LG Steep | LG Slack | XL Steep | XL Slack |
|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.41 mm | 1.4 mm | 1.42 mm | 1.35 mm | 1.36 mm | 1.3 mm | 1.31 mm | 1.24 mm | 1.25 mm |
| Bottom Bracket Height | 336 mm | 327 mm | 338 mm | 327 mm | 338 mm | 327 mm | 338 mm | 327 mm | 338 mm | 327 mm |
| Front Center | 703 mm | 702 mm | 740 mm | 741 mm | 769 mm | 770 mm | 798 mm | 799 mm | 832 mm | 833 mm |
| Rake | 44 mm | 48 mm | 44 mm | 49 mm | 44 mm | 49 mm | 44 mm | 48 mm | 44 mm | 48 mm |
| Trail | 114 mm | 115 mm | 120 mm | 121 mm | 120 mm | 121 mm | 120 mm | 122 mm | 120 mm | 122 mm |
| Stack | 572 mm | 567 mm | 616 mm | 612 mm | 625 mm | 621 mm | 634 mm | 630 mm | 643 mm | 639 mm |
| Reach | 411 mm | 403 mm | 439 mm | 431 mm | 464 mm | 456 mm | 489 mm | 481 mm | 519 mm | 511 mm |
| Top Tube Length | 547 mm | 548 mm | 581 mm | 583 mm | 609 mm | 611 mm | 636 mm | 638 mm | 668 mm | 670 mm |
| Seat Tube Angle | 76.5 ° | 75.7 ° | 76.8 ° | 76 ° | 76.8 ° | 76 ° | 76.8 ° | 76 ° | 76.8 ° | 76 ° |
| Seat Tube Length | 355 mm | 355 mm | 380 mm | 380 mm | 420 mm | 420 mm | 445 mm | 445 mm | 480 mm | 480 mm |
| Head Tube Angle | 65.5 ° | 64.7 ° | 65.8 ° | 65 ° | 65.8 ° | 65 ° | 65.8 ° | 65 ° | 65.8 ° | 65 ° |
| Head Tube Length | 90 mm | 90 mm | 105 mm | 105 mm | 115 mm | 115 mm | 125 mm | 125 mm | 135 mm | 135 mm |
| Chainstay Length | 431 mm | 432 mm | 441 mm | 442 mm | 441 mm | 442 mm | 441 mm | 442 mm | 441 mm | 442 mm |
| Wheelbase | 1133 mm | 1133 mm | 1179 mm | 1179 mm | 1208 mm | 1208 mm | 1237 mm | 1237 mm | 1271 mm | 1271 mm |
| Bottom Bracket Drop | 19 mm | 28 mm | 36 mm | 47 mm | 36 mm | 47 mm | 36 mm | 47 mm | 36 mm | 47 mm |
| Standover Height | 778 mm | 775 mm | 819 mm | 816 mm | 817 mm | 814 mm | 816 mm | 812 mm | 814 mm | 810 mm |
| Wheels | 27" | 27" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 142 cm | 142 cm | 156 cm | 156 cm | 167 cm | 167 cm | 175 cm | 175 cm | 185 cm | 185 cm |
| Rider Max Height | 159 cm | 159 cm | 170 cm | 170 cm | 177 cm | 177 cm | 188 cm | 188 cm | 198 cm | 198 cm |
About this model
Element Carbon 30 completes the Rockymountain Element model. There are 77 bikes that carry this model name. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Rocky Mountain Element Alloy 10 2022 is the most economical model, with a starting price of 2559$. Rocky Mountain Element Carbon 90 2022 on the other hand costs 9589$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Rocky Mountain Element Carbon 30 price was 4259$. Comparing this to the average Trail bike price, we see that the price is 54.2% more expensive.
Average weight for Trail bikes
The average weight for Trail bikes is 12.98 kg (28.62 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Weighing 13.59 kg (29.96 lbs), the Element Carbon 30 model is slightly heavier than average. In conclusion, the average Trail bike weighs 4.7% less than Element Carbon 30.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Element Carbon 30 components
Fork
The Element Carbon 30 comes factory-installed with the Marzocchi Bomber Z2 fork. This has a travel range of 130mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
From the factory, it comes with the Fox Float DPS Performance | Sealed rear shock model, which has a travel of 120mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
As for the wheels, Rocky Mountain Element Carbon 30 2022, has a 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Element Carbon 30 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
There are 10 sizes available for this model. Rider height can be anywhere between 142 cm – 198 cm (4.66 ft – 6.5 ft). In short, you can easily find one that suits you.
Dropper post
Rocky Mountain Element Carbon 30 includes a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
