Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork SunTour XCT
-
Groupset Acera, Altus -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Rocky Mountain 6061 Series Custom Hydroformed Alloy. Threaded BB. Tapered Zerostack Headtube. Rack and Fender Mounts.
Suspension Fork
Suntour XCT 29. 100mm (XS: 80mm) / Preload
Drivetrain
Rear Derailleur
Shimano Acera 9spd
Front Derailleur
Shimano Acera 31.8mm 9spd
Shift Levers
Shimano Altus EZ-Fire 9spd
Cassette
Shimano HG200 11-34T 9spd
Crank
Suntour XCM V1 170-175mm 44/32/22T 9spd
Bottom Bracket
Suntour Sealed Cartridge
Chain
KMC X9 9spd
Wheels
Front Hub
Shimano RM33 / Centerlock / 32H
Rear Hub
Shimano RM33 / Centerlock / 32H
Rims
Wheeltech SX19 By WTB
Spokes
Stainless
Tires
Maxxis Sphinx 29\" x 2.1\"
Brakes
Brakes
Shimano M375 Mechanical Disc 160mm
Brake Levers
Shimano Altus
Cockpit
Stem
Rocky Mountain XC7 7° x 60-90mm
Handlebar
Rocky Mountain Zero6 Flat 31.8mm x 670mm x 6° Sweep
Grips
Rocky Mountain XC Kraton
Headset
FSA #57 Internal: ZS44 | ZS56mm
Seat
Saddle
WTB Volt
Seatpost
Rocky Mountain XC 27.2mm x 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.61 mm | 1.51 mm | 1.48 mm | 1.45 mm |
| Bottom Bracket Height | 318 mm | 318 mm | 318 mm | 318 mm | 318 mm |
| Front Center | 637 mm | 630 mm | 652 mm | 676 mm | 699 mm |
| Rake | 53 mm | 44 mm | 43 mm | 42 mm | 43 mm |
| Trail | 83 mm | 88 mm | 89 mm | 90 mm | 89 mm |
| Stack | 603 mm | 621 mm | 620 mm | 634 mm | 648 mm |
| Reach | 382 mm | 386 mm | 410 mm | 429 mm | 446 mm |
| Top Tube Length | 556 mm | 576 mm | 598 mm | 621 mm | 644 mm |
| Seat Tube Angle | 74 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 355 mm | 394 mm | 432 mm | 470 mm | 508 mm |
| Head Tube Angle | 69.5 ° | 70.25 ° | 70.25 ° | 70.25 ° | 70.25 ° |
| Head Tube Length | 100 mm | 100 mm | 100 mm | 115 mm | 130 mm |
| Chainstay Length | 453 mm | 453 mm | 453 mm | 453 mm | 453 mm |
| Wheelbase | 1084 mm | 1077 mm | 1099 mm | 1123 mm | 1146 mm |
| Bottom Bracket Drop | 56 mm | 56 mm | 56 mm | 56 mm | 56 mm |
| Standover Height | 725 mm | 744 mm | 758 mm | 782 mm | 814 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Fusion 910 belongs to the Rockymountain Fusion model. There are 35 bikes that carry this model name. You can get a glimpse at all models from 2016, by clicking on this link.
Model range prices
The most economical model, the Rocky Mountain Fusion 910 2016 has a starting price of 699$. Rocky Mountain Fusion 940 2016 on the other hand is the most expensive at 999$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2016 for 699$. In conclusion, this bike price is 172.53% lower than the price of the average Crosscountry bike.
Overview of components
Fork
The Fusion 910 comes factory-installed with the SunTour XCT fork. This has a travel range of 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
As for the wheels, Rocky Mountain Fusion 910 2016, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
Fusion 910 comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
