Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
REVEAL FOUR DISC, frame weight starting at 1020g, matt radiator grey 50cm
Suspension Fork
REVEAL FOUR DISC, fork weight starting at 380g matt radiator grey
Drivetrain
Rear Derailleur
Shimano Ultegra RD-R8000 (28-34 t.)
Front Derailleur
Shimano Ultegra FD-R8000
Cassette
Shimano CS-HG700, 11-speed, 11-34
Crank
Shimano Ultegra, FC-R8000, 50/34, 170mm
Chain
Shimano CN-HG601 118 links
Pedals
Pedals are not included and must be ordered separately
Wheels
Rims
ROSE R Thirty Disc, 28 hole
Tires
Continental Grand Prix 5000, black/black 700x30C
Brakes
Brakes
Shimano Ultegra, ST-R8025 / BR-R8070 black
Cockpit
Stem
ROSE Square anodized black 90mm
Handlebar
Ritchey Road Comp Streem II, black/matt 40cm
Seat
Saddle
Rose Edition by Selle Italia, black
Seatpost
ROSE, 8 mm offset 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 53cm | 55cm | 57cm | 59cm | 61cm | 64cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.49 mm | 1.5 mm | 1.53 mm | 1.56 mm | 1.56 mm | 1.56 mm |
| Bottom Bracket Height | 261 mm | 261 mm | 261 mm | 261 mm | 264 mm | 264 mm | 264 mm |
| Front Center | 578 mm | 585 mm | 590 mm | 595 mm | 604 mm | 620 mm | 639 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 63 mm | 61 mm | 59 mm | 56 mm | 57 mm | 56 mm | 54 mm |
| Stack | 535 mm | 557 mm | 571 mm | 588 mm | 604 mm | 621 mm | 642 mm |
| Reach | 367 mm | 374 mm | 380 mm | 384 mm | 388 mm | 399 mm | 411 mm |
| Top Tube Length | 511 mm | 529 mm | 541 mm | 553 mm | 567 mm | 589 mm | 614 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74.25 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 450 mm | 475 mm | 495 mm | 515 mm | 537 mm | 566 mm | 600 mm |
| Head Tube Angle | 71.5 ° | 72 ° | 72.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 120 mm | 142 mm | 154 mm | 170 mm | 190 mm | 208 mm | 230 mm |
| Chainstay Length | 409 mm | 409 mm | 411 mm | 411 mm | 414 mm | 416 mm | 419 mm |
| Wheelbase | 975 mm | 983 mm | 990 mm | 994 mm | 1007 mm | 1026 mm | 1048 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 749 mm | 772 mm | 789 mm | 807 mm | 829 mm | 851 mm | 878 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
REVEAL 04 Ultegra is a Rose Reveal model. There are 59 bikes that carry this model name. Take a sneak peek at all Rose Reveal bikes models from 2023, by clicking here.
Model range prices
The most economical model, the Rose REVEAL AL 105 2023 has a starting price of 1963$. Rose REVEAL SIX DISC Red eTap AXS 2023 on the other hand is the most expensive at 7962$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Endurance bikes average price
Our math shows that the average cost of a dependable Endurance bike is 2346$. However, this doesn’t mean that if you spend less money on an Endurance bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2023 for 3078$. Doing a quick comparison, we notice that REVEAL 04 Ultegra price is 31.2% more expensive than the average cost of an Endurance bike.
Overview of components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The wheels on REVEAL 04 Ultegra are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Rose REVEAL 04 Ultegra has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
