Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
REVEAL FOUR DISC, frame weight starting at 1020g, Matt Carbon/Shiny Red 50cm
Suspension Fork
REVEAL FOUR DISC, fork weight starting at 380g matt black
Drivetrain
Rear Derailleur
Shimano 105, RD7000GS, 11-speed, black
Front Derailleur
Shimano 105, FD-7000-F black
Cassette
Shimano CS-HG700, 11-speed, 11-34
Crank
Shimano 105, FC7000 50/34, black 170mm
Chain
Shimano CN-HG601 118 links
Pedals
Pedals are not included and must be ordered separately
Wheels
Rims
ROSE R25 Disc; 19mm inner rim width; 29"
Tires
Continental Grand Prix 5000 foldable, black/black 700x28C
Brakes
Brakes
Shimano 105, ST-R7025 / BR-R7070, black
Cockpit
Stem
ROSE Square anodized black 90mm
Handlebar
Ritchey Road Comp Streem II, black/matt 40cm
Seat
Saddle
Rose Edition by Selle Italia, black
Seatpost
ROSE, 8 mm offset 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 53cm | 55cm | 57cm | 59cm | 61cm | 64cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.49 mm | 1.5 mm | 1.53 mm | 1.56 mm | 1.56 mm | 1.56 mm |
| Bottom Bracket Height | 261 mm | 261 mm | 261 mm | 261 mm | 264 mm | 264 mm | 264 mm |
| Front Center | 578 mm | 585 mm | 590 mm | 595 mm | 604 mm | 620 mm | 639 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 63 mm | 61 mm | 59 mm | 56 mm | 57 mm | 56 mm | 54 mm |
| Stack | 535 mm | 557 mm | 571 mm | 588 mm | 604 mm | 621 mm | 642 mm |
| Reach | 367 mm | 374 mm | 380 mm | 384 mm | 388 mm | 399 mm | 411 mm |
| Top Tube Length | 511 mm | 529 mm | 541 mm | 553 mm | 567 mm | 589 mm | 614 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74.25 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 450 mm | 475 mm | 495 mm | 515 mm | 537 mm | 566 mm | 600 mm |
| Head Tube Angle | 71.5 ° | 72 ° | 72.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 120 mm | 142 mm | 154 mm | 170 mm | 190 mm | 208 mm | 230 mm |
| Chainstay Length | 409 mm | 409 mm | 411 mm | 411 mm | 414 mm | 416 mm | 419 mm |
| Wheelbase | 975 mm | 983 mm | 990 mm | 994 mm | 1007 mm | 1026 mm | 1048 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 749 mm | 772 mm | 789 mm | 807 mm | 829 mm | 851 mm | 878 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
REVEAL FOUR DISC 105 is part of the Rose Reveal model. Rose launched 59 bikes of this model so far. Take a sneak peek at all Rose Reveal bikes models from 2023, by clicking here.
Model range prices
Rose REVEAL AL 105 2023 is the most economical model, with a starting price of 1963$. Rose REVEAL SIX DISC Red eTap AXS 2023 on the other hand costs 7962$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Endurance bikes average price
According to our math, the average price for a trustworthy Endurance bike is 2346$. However, even if your budget is less than the average, you might still be able to get a top-quality Endurance bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Rose REVEAL FOUR DISC 105 price was 2653$. Comparing this to the average Endurance bike price, we see that the price is 13.09% more expensive.
Overview of components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When it comes to wheels, the REVEAL FOUR DISC 105 bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
