rossignol Ebike Mandate Shift Deore 12 2022
2022 E-bike
Estimate price |
6,422$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 150mm -
Travel Rear 145mm -
Fork RockShox ZEB
-
Groupset Deore, Shimano -
Suspension Full -
Motor Shimano 250W 60Nm mid-drive -
Battery Shimano BT8036 or BT8035-L batteries are fully integrated into the bike frame. Offering 503Wh or 630Wh capacity enables you to ride enough distance for all-day adventures. Take a break and quickly recharge up to 50% capacity in only 2.5hrs. Battery can be easily removed from the frame with a 4mm Allen key. -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Rossignol Trail Electric 145mm travel | 6061 Alloy
Suspension Fork
FS ZEB BASE RUSH RC 29" BOOST 15X110 MXL STEALTH DEBONAIR 150 E-MTB DECAL GLOSS BLACK 44 OFFSET 1.5 TAPER A2, PM200
Rear Shock
RS SUPER DELUXE SELECT+ RT 185X52.5 LINEAR AIR CAN 0 NEG 1 POS TOKENS LINEAR REB-MED COMP TUNE HYDRAULIC BOTTOM OUT 320LB THRESHOLD TRUNNION STANDARD C1
Drivetrain
Rear Derailleur
Shimano Deore M6100
Shift Levers
Shimano Deore M6100, ISPEC EV
Cassette
Shimano Deore M6100, 10-51T
Crank
Shimano EM600, 34T
Chain
Shimano Deore M6100
Chain Guide
e*thirteen e*spec Vario
Pedals
MTB platform pedal
Wheels
Front Hub
Shimano SLX M7110 | J-Bend, Center Lock, 32h, TA 15x110
Rear Hub
Shimano SLX M7110 | J-Bend, Center Lock, 32h, TA 12x148, Micro Spline
Rims
e*thirteen LG1 Enduro with Shimano SLX hubs
Tires
Maxxis DHF, 29x2.6, EXO/TR
Brakes
Brakes
Hydraulic Disc
Brake Levers
Shimano Deore M6100, ISPEC EV
Cockpit
Stem
Rossignol MTB Switch | for internal Di2 routing
Handlebar
Rossignol MTB Switch | Internal routing for di2 | 7075 Aluminum, 20mm rise, Sweep: 9° back, 3° up
Grips
Rossignol lock on, diamond design with waffle grip
Headset
ZS (ZS44/28.6-ZS56/40) / (NO.57)
Seat
Saddle
WTB Silverado, medium, steel
Seatpost
KS EDGE I
Motor & Battery
Motor
Take on steep climbs and tough trails with full confidence and increased maximum torque. Shimano’s newest STEPS MTB EP800 and E7000 motors deliver smooth and direct power to take you anywhere. Compact and lightweight, both motors are quiet and durable enough to hold up to any type of weather.
Battery
Shimano BT8036 or BT8035-L batteries are fully integrated into the bike frame. Offering 503Wh or 630Wh capacity enables you to ride enough distance for all-day adventures. Take a break and quickly recharge up to 50% capacity in only 2.5hrs. Battery can be easily removed from the frame with a 4mm Allen key.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.36 mm | 1.32 mm |
| Bottom Bracket Height | 349 mm | 349 mm | 349 mm |
| Front Center | 753 mm | 765 mm | 791 mm |
| Rake | 47 mm | 43 mm | 46 mm |
| Trail | 123 mm | 127 mm | 124 mm |
| Stack | 605 mm | 609 mm | 618 mm |
| Reach | 431 mm | 447 mm | 467 mm |
| Top Tube Length | 564 mm | 577 mm | 602 mm |
| Seat Tube Angle | 78 ° | 78 ° | 78 ° |
| Seat Tube Length | 375 mm | 425 mm | 445 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1206 mm | 1220 mm | 1247 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
Model Overview
Ebike Mandate Shift Deore 12 is a Rossignol E Ebike model. Rossignol released 5 e-bikes variations of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Rossignol Ebike Mandate Shift Deore 12 2022 is the most affordable e-bike of this model and has a price of 5929$. On the other hand, Rossignol Ebike Mandate Shift XT 2022, is the most expensive and costs 6882$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail e-bikes
If you want an acceptable Trail e-bike you should know that the average price is 3365$. However, this doesn’t mean that if you spend less money on a Trail e-bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
When Rossignol released this model in 2022, its price was 5929$. If we compare this with the average Trail e-bike cost we notice that the price is 76.2% more expensive.
Ebike Mandate Shift Deore 12 components
Fork
Rossignol Ebike Mandate Shift Deore 12 2022 e-bike is equipped with the RockShox ZEB fork, and has 150mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The shock that’s installed on this e-bike is RS SUPER DELUXE SELECT+ RT 185X52.5, with a travel distance of 145mm. Rear shocks improve riding comfort and give you greater control over all terrains. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
The Ebike Mandate Shift Deore 12 2022 e-bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Ebike Mandate Shift Deore 12 comes in 3 sizes, that range from 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Rossignol Ebike Mandate Shift Deore 12 comes with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
