rossignol Ebike Mandate Shift XT 2022
2022 E-bike
Estimate price |
7,454$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 150mm -
Travel Rear 145mm -
Fork Fox Factory Float 38
-
Groupset SRAM, XT -
Suspension Full -
Motor Shimano 250W 60Nm mid-drive -
Battery Shimano BT8036 or BT8035-L batteries are fully integrated into the bike frame. Offering 503Wh or 630Wh capacity enables you to ride enough distance for all-day adventures. Take a break and quickly recharge up to 50% capacity in only 2.5hrs. Battery can be easily removed from the frame with a 4mm Allen key. -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Rossignol Trail Electric 145mm travel | 6061 Alloy
Suspension Fork
2023 FOX E-Optimized 38 - 29" - Factory - 150mm - GRIP2 - Gloss Black - Neutral Logo - QR:15x110 - 1.5T - 44mm Rake
Rear Shock
2023 FOX FLOAT X - Factory - Kashima - EVOL - LSR, 2 Pos Lever, LSC - Metric Trunnion - 185/52.5
Drivetrain
Rear Derailleur
SRAM UDH | Universal Derailleure Hanger
Shift Levers
Shimano Deore XT M8100, ISPEC EV
Cassette
Shimano SLX M7100, 10-51T
Crank
Shimano EM900, 34T
Chain
Shimano SLX M7100
Chain Guide
e*thirteen e*spec Vario
Pedals
MTB platform pedal
Wheels
Front Hub
Shimano Deore XT M8110 | J-Bend, Center Lock, 32h, TA 15x110
Rear Hub
Shimano Deore XT M8110 | J-Bend, Center Lock, 32h, TA 12x148, Micro Spline
Rims
e*thirteen LG1 Plus Enduro with Shimano Deore XT hubs
Tires
Maxxis DHF, 29x2.6, 3C, EXO, TR
Brakes
Brakes
Hydraulic Disc
Brake Levers
Shimano Deore XT M8100, ISPEC EV
Cockpit
Stem
Rossignol MTB Switch | for internal Di2 routing
Handlebar
Rossignol MTB Switch | Internal routing for di2 | 7075 Aluminum, 20mm rise, Sweep: 9° back, 3° up
Grips
Rossignol lock on, diamond design with waffle grip
Headset
ZS (ZS44/28.6-ZS56/40) / (NO.57)
Seat
Saddle
WTB Silverado, medium, cromoly
Seatpost
KS LEV Integra
Motor & Battery
Motor
Take on steep climbs and tough trails with full confidence and increased maximum torque. Shimano’s newest STEPS MTB EP800 and E7000 motors deliver smooth and direct power to take you anywhere. Compact and lightweight, both motors are quiet and durable enough to hold up to any type of weather.
Battery
Shimano BT8036 or BT8035-L batteries are fully integrated into the bike frame. Offering 503Wh or 630Wh capacity enables you to ride enough distance for all-day adventures. Take a break and quickly recharge up to 50% capacity in only 2.5hrs. Battery can be easily removed from the frame with a 4mm Allen key.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.36 mm | 1.32 mm |
| Bottom Bracket Height | 349 mm | 349 mm | 349 mm |
| Front Center | 753 mm | 765 mm | 791 mm |
| Rake | 47 mm | 43 mm | 46 mm |
| Trail | 123 mm | 127 mm | 124 mm |
| Stack | 605 mm | 609 mm | 618 mm |
| Reach | 431 mm | 447 mm | 467 mm |
| Top Tube Length | 564 mm | 577 mm | 602 mm |
| Seat Tube Angle | 78 ° | 78 ° | 78 ° |
| Seat Tube Length | 375 mm | 425 mm | 445 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1206 mm | 1220 mm | 1247 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
Ebike Mandate Shift XT belongs to the Rossignol E Ebike model. There are 5 e-bikes that carry this model name. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Rossignol Ebike Mandate Shift Deore 12 2022 is the most economical model, with a starting price of 5929$. Rossignol Ebike Mandate Shift XT 2022 on the other hand costs 6882$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail e-bikes
If you want an acceptable Trail e-bike you should know that the average price is 3365$. However, even though the average price of a Trail e-bike is lower, you might still be able to get a top-quality e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 6882$. In conclusion, this e-bike price is 104.52% higher than the price of the average Trail e-bike.
Ebike Mandate Shift XT components
Fork
The Ebike Mandate Shift XT comes factory-installed with the Fox Factory Float 38 fork. This has a travel range of 150mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The shock that’s installed on this e-bike is 2023 FOX FLOAT X – Factory, with a travel distance of 145mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
The Ebike Mandate Shift XT 2022 e-bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
This e-bike is available in 3 sizes. They vary from 165 cm – 198 cm (5.41 ft – 6.5 ft). In short, you can easily find one that suits you.
Dropper post
Rossignol Ebike Mandate Shift XT comes with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
