Rotwild R.X750 PRO 2023
2023 E-bike
Estimate price |
11,632$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 150mm -
Travel Rear 152mm -
Fork Fox Factory Float 36
-
Groupset XT, e*thirteen -
Suspension Full -
Motor Brose 90Nm mid-drive -
Battery IPU750 CARBON, IPU750 / 720 Wh / carbon / 3,5 kg / Quick Release / 4,5 A charger -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
full carbon, hand made
Suspension Fork
Fox 36 Float Factory Kashima, 150 mm travel / 110x15 mm / 44 mm offset / OD Crown
Rear Shock
Fox Float X Factory Kashima, 152 mm travel / 205x60 mm / Trunnion (bushing f.) / 19.05 mm (bushing r.)
Drivetrain
Rear Derailleur
Shimano XT 8100
Cassette
SHIMANO CS 7100
Crank
e*thirteen Direct Mount Chainring
Chain
SHIMANO HG 7100
Chain Guide
ROTWILD SL750 2.0
Wheels
Tires
SCHWALBE Magic Mary / Hans Dampf
Brakes
Brakes
SHIMANO XT 8120
Cockpit
Stem
ROTWILD S140 AL7075
Handlebar
ROTWILD B220 Carbon
Headset
ACROS RW750 1.5 Headset
Seat
Saddle
ERGON SM10 Stealth
Seatpost
Eightpins H01
Motor & Battery
Motor
brose Drive S Mag, Brose Drive S Mag / Air Cooler / up to 90 Nm torque
Battery
IPU750 CARBON, IPU750 / 720 Wh / carbon / 3,5 kg / Quick Release / 4,5 A charger
Charger
4,5 A Charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.42 mm | 1.36 mm | 1.3 mm |
| Bottom Bracket Height | 350 mm | 350 mm | 350 mm | 350 mm |
| Front Center | 727 mm | 753 mm | 791 mm | 825 mm |
| Rake | 52 mm | 44 mm | 42 mm | 40 mm |
| Trail | 110 mm | 119 mm | 121 mm | 123 mm |
| Stack | 606 mm | 613 mm | 633 mm | 644 mm |
| Reach | 401 mm | 433 mm | 464 mm | 496 mm |
| Top Tube Length | 584 mm | 613 mm | 650 | 684 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 413 mm | 444 mm | 473 mm | 509 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 110 mm | 110 mm | 130 mm | 140 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1168 mm | 1194 mm | 1232 mm | 1266 mm |
| Bottom Bracket Drop | 15 mm | 15 mm | 15 mm | 15 mm |
| Standover Height | 746 mm | 746 mm | 746 mm | 746 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
R.X750 PRO is a Rotwild E Rx750 model. Rotwild launched 10 e-bikes of this model so far. You can easily view all of the Rotwild E Rx750 e-bikes models from 2023, here.
Model range prices
Rotwild R.X750 CORE 2023 is the most affordable e-bike of this model and has a price of 8493$. On the other hand, Rotwild R.X750 ULTRA 2023, is the most expensive and costs 12740$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Enduro e-bikes average price
According to our calculations, the average cost of an Enduro e-bike that is reliable is 4785$. However, you could also get a good Enduro e-bike even if you pay a lower amount than the average price. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
This e-bike was released in 2023 and its price was 10617$. Comparing the average cost of an Enduro e-bike to this one, you will see that R.X750 PRO price is 121.88% more expensive.
R.X750 PRO components
Fork
The R.X750 PRO comes factory-installed with the Fox Factory Float 36 fork. This has a travel range of 150mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
The shock that’s installed on this e-bike is Fox Float X Factory Kashima, with a travel distance of 152mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
When leaving the production line, the R.X750 PRO model has 29″ wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
When you want to stop the bike in time, the brakes are vital. The R.X750 PRO has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
A dropper post is included with the R.X750 PRO. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
