rraymon R RAYMON CrossRay E 8.0 2021
2021 E-bike
Estimate price |
4,652$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Fork Suntour MOBIE -
Groupset XT, Deore -
Suspension Hardtail -
Motor Yamaha 250W 80Nm mid-drive -
Battery Simplo EnergyTube, 630 Wh, 36 V -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
27.5", Alloy 6061, Integrated battery
Suspension Fork
SR SUNTOUR Mobie-A32
Drivetrain
Rear Derailleur
Shimano Deore XT, RD-M8100, Shadow Plus, 12-S
Shift Levers
Shimano Deore, SL-M6100, Rapidfire Plus, 12-speed
Cassette
Shimano CS-M6100, 10-51 T
Chain
KMC e12S
Pedals
R Raymon, Alloy
Wheels
Rims
Rim: Mach1 Trucky30, Hubs: R Raymon DA210, 15x100/12x148mm
Tires
Schwalbe Johnny Watts, Performance, Reflex, 60-584, 27.5x2.35
Brakes
Brakes
Shimano BR-MT410, 2-piston, Hydraulic disc brake
Cockpit
Stem
R Raymon 31.8, adjustable
Handlebar
R Raymon 31.8 mm, 700 mm, Sweep: 9 °, Rise: 15 mm
Grips
R Raymon Ergo, Lock-on grips
Seat
Saddle
R Raymon Ergo
Seatpost
R Raymon, 30.9 mm, Patent
Motor & Battery
Motor
Yamaha PW-X2, 250W, 80Nm
Battery
Simplo EnergyTube, 630 Wh, 36 V
Remote
Yamaha Display C, LCD-Display, Bluetooth
Charger
Simplo rapid charger, 4 A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.39 mm | 1.38 mm | 1.37 mm |
| Front Center | 696 mm | 710 mm | 723 mm | 737 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 76 mm | 76 mm | 76 mm | 76 mm |
| Stack | 609 mm | 618 mm | 628 mm | 637 mm |
| Reach | 435 mm | 445 mm | 455 mm | 465 mm |
| Top Tube Length | 611 mm | 624 mm | 636 mm | 649 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 480 mm | 520 mm | 560 mm | 600 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 130 mm | 140 mm | 150 mm | 160 mm |
| Chainstay Length | 470 mm | 470 mm | 470 mm | 470 mm |
| Wheelbase | 1160 mm | 1174 mm | 1187 mm | 1201 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
CrossRay E 8.0 is a Rraymon E Crossray model. 13 e-bikes variations carry this model name so far. Take a sneak peek at all Rraymon E Crossray e-bikes models from 2021, by clicking here.
Model range prices
R RAYMON CrossRay E 4.0 2021 is the most affordable e-bike of this model and has a price of 2972$. On the other hand, R RAYMON CrossRay E 8.0 2021, is the most expensive and costs 4246$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Hybrid e-bikes average price
If you want an acceptable Hybrid e-bike you should know that the average price is 2480$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Hybrid e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
This e-bike was released in 2021 and its price was 4246$. If we compare this with the average Hybrid e-bike cost we notice that the price is 71.21% higher.
CrossRay E 8.0 components
Fork
The CrossRay E 8.0 comes factory-installed with the Suntour MOBIE fork. This has a travel range of mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The wheels on CrossRay E 8.0 are the aluminum type. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The CrossRay E 8.0 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
This e-bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
