rraymon R RAYMON UrbanRay 1.0 2021
2021 Urban
Estimate price |
1,023$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame aluminium -
Wheels 700c -
Groupset Nexus -
Suspension Rigid -
Drivetrain Internally Geared Hub -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
28", Alloy 6061
Suspension Fork
R Raymon Alloy
Drivetrain
Shift Levers
Shimano Nexus, SL-C3000, Revoshift
Cassette
Shimano SM-Gear, 18
Crank
R Raymon, Alloy
Chain
KMC Z1 Wide
Pedals
R Raymon, plastic
Wheels
Rims
Shimano SM-Gear, 18
Tires
Continental Speed RIDE, Reflex, 42-622, 28x1.6
Brakes
Brakes
Shimano BR-MT200, 2-piston, Hydraulic disc brake
Cockpit
Stem
R Raymon 31.8, Ahead
Handlebar
R Raymon Riser 31.8 mm, 640 mm, Rise: 18 mm
Grips
R Raymon Ergo
Seat
Seatpost
R Raymon, 30.9 mm, Patent
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.39 mm | 1.39 mm | 1.34 mm |
| Front Center | 628 mm | 649 mm | 660 mm | 685 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 76 mm | 76 mm | 76 mm | 76 mm |
| Stack | 570 mm | 579 mm | 589 mm | 598 mm |
| Reach | 398 mm | 416 mm | 424 mm | 446 mm |
| Top Tube Length | 574 mm | 595 mm | 605 mm | 630 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 480 mm | 520 mm | 560 mm | 600 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 140 mm | 150 mm | 160 mm | 170 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1063 mm | 1084 mm | 1095 mm | 1120 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
UrbanRay 1.0 completes the Rraymon Urbanray model. 3 bikes variations carry this model name so far. You can easily view all of the Rraymon Urbanray bikes models from 2021, here.
Model range prices
The most economical model, the R RAYMON UrbanRay 1.0 2021 has a starting price of 933$. R RAYMON UrbanRay 3.0 2021 on the other hand is the most expensive at 1432$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
General Urban bikes average price
If you want an acceptable General Urban bike you should know that the average price is 499$. However, paying less money than this amount doesn’t mean that you couldn’t get a great General Urban bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 933$. Comparing the average cost of a General Urban bike to this one, you will see that UrbanRay 1.0 price is 86.97% more expensive.
UrbanRay 1.0 components
Fork material
When it comes to the fork, this bike has an aluminum one, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels size
The UrbanRay 1.0 2021 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
