Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon CC
Suspension Fork
Stigmata CC Cyclocross Fork
Drivetrain
Rear Derailleur
Shimano Ultegra 6800
Front Derailleur
Shimano Ultegra 6800
Shift Levers
Shimano Ultegra
Cassette
Shimano Ultegra 6800; 11-32t
Crank
Shimano Ultegra, 50/34 tooth
Bottom Bracket
Included w/ crankset
Chain
Shimano SLX M7000
Wheels
Front Hub
DT Swiss 240 Centerlock
Rear Hub
DT Swiss 240 Centerlock
Rims
WTB Asym i19
Spokes
DT Swiss Competition Double-Butted
Tires
Maxxis Rambler TR 700Cx40mm
Brakes
Brakes
Shimano Ultegra
Disk Rotors
Shimano RT99; 140mm F/R
Cockpit
Stem
Zipp Service Course SL
Handlebar
Zipp Service Course SL
Grips
Santa Cruz Perforated
Headset
Cane Creek 110, Integrated
Seat
Saddle
WTB Silverado Road
Seatpost
Zipp SL Speed-20 Carbon, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.49 mm | 1.51 mm | 1.53 mm | 1.51 mm |
| Bottom Bracket Height | 280 mm | 280 mm | 280 mm | 280 mm | 280 mm |
| Front Center | 598 mm | 604 mm | 609 mm | 614 mm | 633 mm |
| Rake | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 69 mm | 66 mm | 63 mm | 60 mm | 60 mm |
| Stack | 539 mm | 560 mm | 576 mm | 592 mm | 607 mm |
| Reach | 373 mm | 377 mm | 382 mm | 386 mm | 402 mm |
| Top Tube Length | 524 mm | 539 mm | 554 mm | 569 mm | 589 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 530 mm | 545 mm | 560 mm | 570 mm | 590 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 125 mm | 145 mm | 160 mm | 175 mm | 190 mm |
| Chainstay Length | 419 mm | 419 mm | 419 mm | 419 mm | 419 mm |
| Wheelbase | 1007 mm | 1013 mm | 1018 mm | 1023 mm | 1043 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 764 mm | 780 mm | 788 mm | 796 mm | 813 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
Stigmata CC CX1 is a Santacruz Stigmata model. Santa Cruz released 43 bikes variations of this model so far. You can easily view all of the Santacruz Stigmata bikes models from 2017, here.
Model range prices
Santa Cruz Stigmata C Rival 2017 is the most affordable bike of this model and has a price of 3299$. On the other hand, Santa Cruz Stigmata CC Ult. 2017, is the most expensive and costs 6800$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Gravel bikes
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2017 and its price was 4499$. Doing a quick comparison, we notice that Stigmata CC CX1 price is 82.74% higher than the average cost of a Gravel bike.
Stigmata CC CX1 components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
As for the wheels, Santa Cruz Stigmata CC CX1 2017, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Stigmata CC CX1 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
