Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 26" -
Travel Front 100mm -
Fork RST DIRT
-
Suspension Hardtail -
Drivetrain Single Speed -
Brakes Mechanical Disc
Sizing
Recommended size guide.
MD
154cm - 180cm
LG
178cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AMPLITUDE 4130 CRO-MO TUBESET. Headtube: IS42-IS42 headtube. Dropout Design: singlespeed specific.
Suspension Fork
RST DIRT RA. Travel: 100mm. Technology: Rebound adjust. Axle: QR axle.
Drivetrain
Cassette
STEEL 12T. Speed: singlespeed.
Crank
SAMOX CRO-MO 3-PC. Chain Ring: 25T. Crank Length: 175mm.
Bottom Bracket
MID TYPE SEALED BEARING. Type: 8T spline.
Chain
KMC Z1.
Wheels
Front Hub
FORMULA. Front: Formula DC-20N. Rear: Formula DC-52N. Brake Fitting: 6-bolt. Front Axle Type: QR. Rear Axle Type: 10 x 135 Nutted axle. Hole: 32H.
Rear Hub
FORMULA. Front: Formula DC-20N. Rear: Formula DC-52N. Brake Fitting: 6-bolt. Front Axle Type: QR. Rear Axle Type: 10 x 135 Nutted axle. Hole: 32H.
Rims
JALCO DD32. Hole: 32H. Size: 26''. Tubeless Ready: No.
Spokes
STEEL 14G.
Tires
MAXXIS. Model: DTH Wire bead. Size: 26 x 2.3.
Brakes
Brakes
TEKTRO. Model: MD-300. Brake Type: Cable disc. Rotor Size: 160/160mm.
Brake Levers
TEKTRO RS-360.
Cockpit
Stem
RACEFACE CHESTER. Length: 35mm. Rise: 0 degree. Clamp: 35mm. Type: Ahead.
Handlebar
RACEFACE CHESTER. Width: 780mm. Rise: 35mm. Bar Bore: 35mm.
Grips
ODI ELITE MOTION.
Headset
FSA NO.8D.
Seat
Saddle
SARACEN CUSTOM INTEGRATED.
Seatpost
SARACEN. Type: Integrated with saddle. Size: 27.2mm.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.3 mm |
| Bottom Bracket Height | 328 mm | 328 mm |
| Front Center | 643 mm | 653 mm |
| Rake | 24 mm | 19 mm |
| Trail | 109 mm | 115 mm |
| Stack | 551 mm | 551 mm |
| Reach | 409 mm | 425 mm |
| Top Tube Length | 577 mm | 592 mm |
| Seat Tube Angle | 73 ° | 73 ° |
| Seat Tube Length | 300 mm | 300 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° |
| Head Tube Length | 115 mm | 115 mm |
| Chainstay Length | 402 mm | 402 mm |
| Wheelbase | 1045 mm | 1055 mm |
| Bottom Bracket Drop | 15 mm | 15 mm |
| Wheels | 26" | 26" |
| Rider Min Height | 154 cm | 178 cm |
| Rider Max Height | 180 cm | 190 cm |
About this model
Amplitude CR2 is a Saracen Amplitude model. Saracen released 11 bikes variations of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
The most economical model, the Saracen Amplitude CR2 – blue 2023 has a starting price of 729$. Saracen Amplitude AL Team 2023 on the other hand is the most expensive at 1156$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Dirt Jump bikes average price
If you want an acceptable Dirt Jump bike you should know that the average price is 863$. However, you could also get a good Dirt Jump bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2023 for 851$. Comparing this to the average Dirt Jump bike price, we see that the price is 1.41% lower.
Amplitude CR2 components
Fork
This bike has the RST DIRT fork installed. The fork’s travel is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
When leaving the production line, the Amplitude CR2 model has 26″ aluminum wheels. These wheels give you great handling over your bike. However, they provide less traction than 29″ wheels do.
Brakes
For your safety, it is important to have quality breaks on your bike. Saracen Amplitude CR2 has Mechanical Disc brakes installed. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
Saracen Amplitude CR2 bike has 2 sizes, in the range of 154 cm – 190 cm (5.05 ft – 6.23 ft). In conclusion, you won’t have a problem finding one that suits you.
