Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 26" -
Travel Front 100mm -
Fork RST SPACE
-
Suspension Hardtail -
Drivetrain Single Speed -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
154cm - 180cm
LG
178cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AMPLITUDE 4130 CRO-MO TUBESET. Headtube: IS42-IS42 headtube. Dropout Design: singlespeed specific.
Suspension Fork
RST SPACE FREE COIL. Travel: 100mm. Technology: Rebound adjust. Axle: 20mm thru-axle.
Drivetrain
Cassette
STEEL 12T. Speed: singlespeed.
Crank
SAMOX CRO-MO 2-PC. Chain Ring: 25T. Crank Length: 175mm.
Bottom Bracket
MID TYPE SEALED BEARING. Type: 48T spline.
Chain
KMC K1.
Wheels
Front Hub
FORMULA. Front: Formula DHL-92. Rear: Formula DC-52N. Brake Fitting: 6-bolt. Front Axle Type: 20 x 110. Rear Axle Type: 10 x 135 Nutted axle. Hole: 32H.
Rear Hub
FORMULA. Front: Formula DHL-92. Rear: Formula DC-52N. Brake Fitting: 6-bolt. Front Axle Type: 20 x 110. Rear Axle Type: 10 x 135 Nutted axle. Hole: 32H.
Rims
JALCO DD32. Hole: 32H. Size: 26''. Tubeless Ready: No.
Spokes
STEEL 14G.
Tires
MAXXIS. Model: DTH Wire bead. Size: 26 x 2.3.
Brakes
Brakes
TEKTRO. Model: HD-M275. Brake Type: Hydraulic two piston. Rotor Size: 160/160mm.
Brake Levers
TEKTRO HD-M275.
Cockpit
Stem
RACEFACE CHESTER. Length: 35mm. Rise: 0 degree. Clamp: 35mm. Type: Ahead.
Handlebar
RACEFACE CHESTER. Width: 780mm. Rise: 35mm. Bar Bore: 35mm.
Grips
ODI ELITE MOTION.
Headset
FSA NO.8D.
Seat
Saddle
SARACEN CUSTOM INTEGRATED.
Seatpost
SARACEN. Type: Integrated with saddle. Size: 27.2mm.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.3 mm |
| Bottom Bracket Height | 328 mm | 328 mm |
| Front Center | 643 mm | 653 mm |
| Rake | 24 mm | 19 mm |
| Trail | 109 mm | 115 mm |
| Stack | 551 mm | 551 mm |
| Reach | 409 mm | 425 mm |
| Top Tube Length | 577 mm | 592 mm |
| Seat Tube Angle | 73 ° | 73 ° |
| Seat Tube Length | 300 mm | 300 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° |
| Head Tube Length | 115 mm | 115 mm |
| Chainstay Length | 402 mm | 402 mm |
| Wheelbase | 1045 mm | 1055 mm |
| Bottom Bracket Drop | 15 mm | 15 mm |
| Wheels | 26" | 26" |
| Rider Min Height | 154 cm | 178 cm |
| Rider Max Height | 180 cm | 190 cm |
About this model
Amplitude CR3 is part of the Saracen Amplitude model. There are 11 bikes that carry this model name. Take a sneak peek at all Saracen Amplitude bikes models from 2023, by clicking here.
Model range prices
The most economical model, the Saracen Amplitude CR2 – blue 2023 has a starting price of 729$. Saracen Amplitude AL Team 2023 on the other hand is the most expensive at 1156$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Dirt Jump bikes average price
According to our calculations, the average cost of a Dirt Jump bike that is reliable is 863$. However, even if your budget is less than the average, you might still be able to get a top-quality Dirt Jump bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Saracen released this model in 2023, its price was 1156$. In conclusion, this bike price is 33.95% more expensive than the price of the average Dirt Jump bike.
Amplitude CR3 components
Fork
This bike has the RST SPACE fork installed. The fork’s travel is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
The Amplitude CR3 2023 bike is equipped with 26″ aluminum wheels when leaving the factory. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
For your safety, it is important to have quality breaks on your bike. Saracen Amplitude CR3 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
This bike is available in 2 sizes. They vary from 154 cm – 190 cm (5.05 ft – 6.23 ft). In short, you can easily find one that suits you.
