Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 160mm -
Travel Rear 160mm -
Fork Fox Factory Float 38
-
Groupset XT -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 172cm
MD
170cm - 180cm
LG
178cm - 186cm
XL
184cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SERIES 3 CUSTOM BUTTED AND HYDROFORMED 6013 ALLOY FRONT TRIANGLE AND SWINGARM. Headtube: ZS44-ZS56 tapered headtube. Bearings: 37mm main pivot bearings / 28mm linkage bearings. Linkage: Convertible CNC linkage included for both mullet and 29er setups. Suspension: Signature TRL suspension design. Cable Routing: Internal. Axle: 12 x 157mm SuperBoost dropout system. Rear Travel: 160mm.
Suspension Fork
FOX 38 FACTORY. Travel: 160mm. Technology: Tapered steerer / HSC LSC HSR LSR adjust / Grip2 damper. Axle: 15x110 Boost. Rake: 44mm.
Rear Shock
FOX DHX2 FACTORY. Adjustment: HSC LSC HSR LSR adjust / 2 position adjust / SLS spring. Length / Stroke: 230 x 65.
Drivetrain
Rear Derailleur
SHIMANO XT. Model: M8100 SGS Shadow Plus. Speed: 12 speed.
Shift Levers
SHIMANO XT. Model: M8100 Rapidfire Plus 2-way release. Speed: 1x12 speed.
Cassette
SHIMANO XT. Model: M8100. Speed: 12 speed. Ratio: 10-51T.
Crank
SHIMANO XT. Model: FC-M8130. Chain Ring: 32T. Crank Length: 170mm / 56.5mm.
Bottom Bracket
SHIMANO BB-MT800 73MM.
Chain
KMC X12.
Wheels
Front Hub
SHIMANO. Front: XT HB-M8110 32H. Rear: XT FH-M8130 32H. Brake Fitting: Centre-lock. Front Axle Type: 15 x 110 Boost. Rear Axle Type: 12 x 157 SuperBoost. Hole: 32H.
Rear Hub
SHIMANO. Front: XT HB-M8110 32H. Rear: XT FH-M8130 32H. Brake Fitting: Centre-lock. Front Axle Type: 15 x 110 Boost. Rear Axle Type: 12 x 157 SuperBoost. Hole: 32H.
Rims
DT SWISS EX 511. Hole: 32H. Size: 29'' Front / 29'' Rear (Sizes Large / XL) 29'' Front / 27.5'' Rear (Sizes Small / Medium). Tubeless Ready: Yes.
Spokes
DOUBLE-BUTTED STAINLESS STEEL.
Tires
MAXXIS MINION DHRII. Model: EXO TR. Size: 29 x 2.4 Front & Rear (Sizes Large / XL) / 29 x 2.4 Front / 27.5 x 2.3 Rear (Sizes Small / Medium).
Brakes
Brakes
SHIMANO XT. Model: BR-M8120. Brake Type: Hydraulic four piston. Rotor Size: 203/203mm.
Brake Levers
SHIMANO XT.
Cockpit
Stem
RACEFACE TURBINE R 35. Length: 40mm. Rise: 0 degree. Clamp: 35mm. Type: Ahead.
Handlebar
RACEFACE NEXT R CARBON. Width: 780mm. Rise: 35mm. Bar Bore: 35mm.
Grips
ODI ELITE MOTION.
Headset
PRESTINE PT-F13.
Seat
Saddle
SARACEN CUSTOM CRMO MTB.
Seatpost
KS LEV INTEGRA. Routing: Internal. Size: 30.9mm. Travel: 150mm, 125mm on size small. Lever: Southpaw remote.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.3 mm | 1.26 mm | 1.23 mm |
| Front Center | 781 mm | 808 mm | 839 mm | 871 mm |
| Rake | 41 mm | 40 mm | 40 mm | 41 mm |
| Trail | 132 mm | 134 mm | 134 mm | 132 mm |
| Stack | 612 mm | 617 mm | 630 mm | 644 mm |
| Reach | 449 mm | 474 mm | 499 mm | 524 mm |
| Top Tube Length | 597 mm | 618 mm | 646 mm | 674 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 76.5 ° | 76.5 ° |
| Seat Tube Length | 360 mm | 410 mm | 460 mm | 510 mm |
| Head Tube Angle | 64.6 ° | 64.6 ° | 64.6 ° | 64.6 ° |
| Head Tube Length | 105 mm | 110 mm | 125 mm | 140 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1214 mm | 1241 mm | 1272 mm | 1304 mm |
| Bottom Bracket Drop | 27 mm | 27 mm | 27 mm | 27 mm |
| Standover Height | 729 mm | 729 mm | 730 mm | 730 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 154 cm | 170 cm | 178 cm | 184 cm |
| Rider Max Height | 172 cm | 180 cm | 186 cm | 196 cm |
Model Overview
Ariel 60 Elite belongs to the Saracen Ariel model. Saracen launched 21 bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Saracen Ariel Junior 2023 is the most economical model, with a starting price of 2313$. Saracen Ariel 60 Elite 2023 on the other hand costs 5357$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Enduro bikes
According to our math, the average price for a trustworthy Enduro bike is 3599$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2023 and its price was 5357$. In conclusion, this bike price is 48.85% higher than the price of the average Enduro bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
The Fox Factory Float 38 is included from the factory. It has a travel distance of 160mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
The shock that’s installed on this bike is FOX DHX2 FACTORY. Adjustment: HSC LSC, with a travel distance of 160mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
The wheels on Ariel 60 Elite are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Nothing is more important on a bike than its ability to brake properly. Saracen Ariel 60 Elite is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 154 cm – 196 cm (5.05 ft – 6.43 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Saracen Ariel 60 Elite includes a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
