schindelhauer Friedrich VIII/XI 2023
2023 Urban
Estimate price |
3,199$
Weight | 13.2 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Alfine -
Suspension Rigid -
Drivetrain Internally Geared Hub -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
151cm - 164cm
MD
161cm - 177cm
LG
174cm - 187cm
XL
184cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium (AL6061-T6), triple butted aero tubing, forged dropouts with slider-belt-tensioning-system and Schindelhauer belt port, integrated seat post clamp, internal cable routing, smooth welded
Suspension Fork
Aluminium fork (tapered), 15mm through-axle, for flat mount disc brakes
Drivetrain
Shift Levers
Shimano - Alfine 8-speed/11-speed internal gear hub
Crank
Shimano - Alfine Hollowtech II
Bottom Bracket
BSA, Shimano - Alfine Hollowtech II
Pedals
Schindelhauer - Urban Pedal, aluminium, CNC machined
Wheels
Rims
Shutter Precision - PD-8X hub dynamo disc, Shimano - Alfine 8-/11-speed internal gear hub, Alexrims - CXD26 rims with eyelets, Sapim - Race spokes, 3-cross and 2-cross laced
Tires
Continental - GP Urban Classic 35-622
Brakes
Brakes
Shimano - Alfine S7000 disc brake (hydraulic), 160mm
Cockpit
Stem
Schindelhauer
Handlebar
Satori - Noirette Plus, aluminium
Grips
Schindelhauer - ergo leather grips
Headset
Tange Seiki - integrated, tapered 1 1/8“-1,5“
Seat
Saddle
Brooks - B17
Seatpost
Schindelhauer
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.358 mm | 1.371 mm | 1.356 mm | 1.354 mm |
| Stack | 565 mm | 580 mm | 594 mm | 608 mm |
| Reach | 416 mm | 423 mm | 438 mm | 449 mm |
| Top Tube Length | 570 mm | 585 mm | 610 mm | 625 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Head Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 140 mm | 155 mm | 170 mm | 185 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1061 mm | 1072 mm | 1093 mm | 1108 mm |
| Standover Height | 795 mm | 820 mm | 845 mm | 856 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 161 cm | 174 cm | 184 cm |
| Rider Max Height | 164 cm | 177 cm | 187 cm | 198 cm |
Model Overview
Friedrich VIII/XI belongs to the Schindelhauer Friedrich model. There are 5 bikes that carry this model name. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Schindelhauer Friedrich VIII/XI 2023 is the most affordable bike of this model and has a price of 2920$. On the other hand, Schindelhauer Friedrich XI 2023, is the most expensive and costs 3180$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Commuter bikes average price
According to our calculations, the average cost of a Commuter bike that is reliable is 762$. However, this doesn’t mean that if you spend less money on a Commuter bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Schindelhauer released this model in 2023, its price was 2920$. Comparing the average cost of a Commuter bike to this one, you will see that Friedrich VIII/XI price is 283.2% more expensive.
Commuter bikes average weight
The average weight for Commuter bikes is 13.77 kg (30.36 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Weighing 13.2 kg (29.1 lbs), the Friedrich VIII/XI model is slightly lighter than average. In other words, this model is 4.32% lighter than the average Commuter bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Friedrich VIII/XI components
Fork material
When it comes to the fork, this bike has an aluminum one, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels
When leaving the production line, the Friedrich VIII/XI model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
This bike is available in 4 sizes. They vary from 151 cm – 198 cm (4.95 ft – 6.5 ft). In conclusion, it won’t take much to find one that’s right for you.
