Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Claris -
Suspension Rigid -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
N LITENED 3 aluminum, 700c road tuned geometry, internal cable routing, 10 mm x 135 mm dropout, replaceable hanger, 1 1/8 in headtube
Suspension Fork
Schwinn® road-tuned N LITENED GOLD® triple-butted aluminum road frame and aluminum fork
Drivetrain
Rear Derailleur
Shimano Claris
Front Derailleur
Shimano Claris, 31.8 mm clamp
Shift Levers
Shimano Claris, 16-speed
Crank
Schwinn road, 50/34T
Bottom Bracket
VP, cartridge, square taper, 68 mm
Chain
KMC Z8.1
Pedals
Schwinn road, nylon, toe clips and straps
Wheels
Front Hub
Schwinn road, aluminum, 9 mm x 100 mm QR, 32H
Rear Hub
Schwinn road, aluminum, 10 mm x 130 mm QR, 32H
Rims
Alex® X2200 double-wall rims with Schwinn® aluminum road hubs
Spokes
14G, stainless steel
Tires
Schwinn road, 700c x 25c, wire bead
Brakes
Brakes
Promax® aluminum caliper brakes
Cockpit
Stem
Schwinn, aluminum, threadless, - 7° rise, 31.8 mm clamp
Grips
Schwinn road, gel cork tape
Headset
Threadless, ZS44, semi-cartridge bearings
Seat
Saddle
Schwinn race, steel rails
Seatpost
Aluminum, 350 mm, 16 mm offset, 27.2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | SM/MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 574 mm | 585 mm | 586 mm | 595 mm | 600 mm | 613 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Top Tube Length | 521 mm | 536 mm | 551 mm | 566 mm | 581 mm | 601 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 440 mm | 470 mm | 500 mm | 530 mm | 550 mm | 590 mm |
| Head Tube Angle | 72 ° | 72 ° | 73 ° | 73 ° | 73.5 ° | 73.5 ° |
| Head Tube Length | 125 mm | 140 mm | 155 mm | 170 mm | 190 mm | 215 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 431 mm | 431 mm | 431 mm |
| Wheelbase | 995 mm | 1006 mm | 1007 mm | 1016 mm | 1021 mm | 1034 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 710 mm | 710 mm | 734 mm | 759 mm | 782 mm | 834 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Fastback AL Claris belongs to the Schwinn Fastback model. Schwinn released 13 bikes variations of this model so far. Take a sneak peek at all Schwinn Fastback bikes models from 2020, by clicking here.
Model range prices
Schwinn Fastback AL Claris 2020 is the cheapest bike model and costs 699$. Schwinn Fastback Carbon 105 2020 is the most expensive one and costs 1999$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Endurance bikes
According to our math, the average price for a trustworthy Endurance bike is 2346$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Endurance bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2020 for 699$. Comparing this to the average Endurance bike price, we see that the price is 235.62% smaller.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
The fork is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
When it comes to wheels, the Fastback AL Claris bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
