Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Brakes Rim
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
N LITENED Black Label carbon, 700c road tuned geometry, internal cable routing, 10 mm x 135 mm dropout, replaceable hanger, tapered headtube
Suspension Fork
Schwinn® road-tuned N LITENED® Black Label™ Carbon frame and Schwinn® race carbon fork
Drivetrain
Rear Derailleur
Shimano 105 RD-R7000
Front Derailleur
Shimano 105 FD-R7000, 34.9 mm clamp
Shift Levers
Shimano 105 ST-R7000, 22-speed
Crank
Shimano 105 FC-R7000, 50/34T
Bottom Bracket
Shimano, sealed external bearing, 68 mm
Chain
Shimano CN-HG601
Pedals
Schwinn road, nylon, toe clips and straps
Wheels
Front Hub
Shimano WH-RS100, aluminum, 9 mm x 100 mm QR, 20H
Rear Hub
Shimano WH-RS100, aluminum, 10 mm x 130 mm QR, 24H
Rims
Shimano WH-RS100, aluminum, double wall, 20H front, 24H rear
Spokes
14G, stainless steel
Tires
Kenda Kriterium, 700c x 25c, folding bead
Brakes
Brakes
Shimano® 105 dual-pivot caliper brakes
Cockpit
Stem
Schwinn, aluminum, threadless, - 7° rise, 31.8 mm clamp
Grips
Schwinn road, Silicon gel tape
Headset
Threadless, IS42 / IS52, sealed bearings
Seat
Saddle
Schwinn S1 race, steel rails
Seatpost
Aluminum, 300 mm, 16 mm offset, 31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.46 mm | 1.55 mm | 1.64 mm | 1.65 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 576 mm | 586 mm | 584 mm | 585 mm | 599 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 72 mm | 70 mm | 63 mm | 56 mm | 57 mm |
| Stack | 519 mm | 541.6 mm | 570.9 mm | 603.1 mm | 622.3 mm |
| Reach | 364 mm | 371.3 mm | 368.6 mm | 368.7 mm | 377.5 mm |
| Top Tube Length | 513 mm | 532 mm | 549 mm | 565 mm | 586 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 72.5 ° | 72 ° | 71.5 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm | 540 mm | 570 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 72 ° | 73 ° | 73 ° |
| Head Tube Length | 116 mm | 138 mm | 165 mm | 195 mm | 215 mm |
| Chainstay Length | 407 mm | 409 mm | 412 mm | 414 mm | 416 mm |
| Wheelbase | 973 mm | 985 mm | 986 mm | 989 mm | 1005 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 711 mm | 738 mm | 768 mm | 800 mm | 825 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Fastback Carbon 105 completes the Schwinn Fastback model. Schwinn released 13 bikes variations of this model so far. Check out the entire range from 2020 of this model, by clicking this link.
Model range prices
Schwinn Fastback AL Claris 2020 is the cheapest bike model and costs 699$. Schwinn Fastback Carbon 105 2020 is the most expensive one and costs 1999$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Endurance bikes
If you want to purchase a solid Endurance bike, it is important to know that the average cost is 2346$. However, you could also get a good Endurance bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Schwinn released this model in 2020, its price was 1999$. Doing a quick comparison, we notice that Fastback Carbon 105 price is 17.36% smaller than the average cost of an Endurance bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The wheels on Fastback Carbon 105 are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
This bike is available in 5 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
