Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Acera, Tourney -
Suspension Rigid -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
N LITENED 3 aluminum, 700c crossfit tuned geometry, S.R.T. (Smooth Ride Technology) Elastomer, 10 mm x 135 mm dropout, replaceable hanger, 1 1/8 in headtube
Suspension Fork
Schwinn® crossfit-tuned NLITENED 3®, Smooth Ride Technology (S.R.T.) endurance frame with elastomer technology and aluminum fork
Drivetrain
Rear Derailleur
Shimano Acera RD-M360
Front Derailleur
Shimano FD-TY700, 31.8 mm clamp
Shift Levers
Shimano EF500 EZ-FIRE, 24-speed
Crank
SR Suntour XCE, 48/38/28T
Bottom Bracket
VP, cartridge, square taper, 68 mm
Chain
KMC Z8.1
Pedals
Schwinn sport, aluminum / nylon
Wheels
Front Hub
Formula DC1420, aluminum, 9 mm x 100 mm QR, 32H, 6-bolt
Rear Hub
Formula DC1422, aluminum, 10 mm x 135 mm QR, 32H, 6-bolt
Rims
Alex DC26, aluminum, double wall, 32H
Spokes
14G, stainless steel
Tires
Kenda Kwest, 700c x 35c, wire bead
Brakes
Brakes
Promax® mechanical disc brakes
Cockpit
Stem
Schwinn, aluminum, threadless, 7° rise, 31.8 mm clamp
Grips
Schwinn ergo, dual density
Headset
Threadless, ZS44, semi-cartridge bearings
Seat
Saddle
Schwinn sport, steel rails
Seatpost
Aluminum, 350 mm, 25 mm offset, 27.2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Front Center | 589 mm | 611 mm | 616 mm | 622 mm | 635 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Top Tube Length | 526 mm | 546 mm | 561 mm | 576 mm | 596 mm |
| Seat Tube Angle | 74 ° | 74.5 ° | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 430 mm | 450 mm | 480 mm | 510 mm | 560 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 140 mm | 160 mm | 180 mm | 205 mm | 235 mm |
| Chainstay Length | 426 mm | 431 mm | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1004 mm | 1031 mm | 1036 mm | 1043 mm | 1056 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 70 mm | 70 mm |
| Standover Height | 741 mm | 746 mm | 769 mm | 800 mm | 847 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Vantage F2 completes the Schwinn Vantage model. Schwinn released 9 bikes variations of this model so far. Take a sneak peek at all Schwinn Vantage bikes models from 2020, by clicking here.
Model range prices
Schwinn Vantage F3 2020 is the most economical model, with a starting price of 539$. Schwinn Vantage RX1 2020 on the other hand costs 1729$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Fitness bikes
If you want to purchase a solid Fitness bike, it is important to know that the average cost is 656$. However, you could also get a good Fitness bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Schwinn released this model in 2020, its price was 699$. Comparing this to the average Fitness bike price, we see that the price is 6.55% higher.
Overview of components
Fork material
The fork on this bike is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
The wheels on Vantage F2 are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Schwinn Vantage F2 has Mechanical Disc brakes installed. They are much easier to maintain than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
