Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset GRX 400, FSA -
Suspension Rigid -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
N LITENED 3 aluminum, 700c adventure tuned geometry, S.R.T. (Smooth Ride Technology) Elastomer, 12 mm x 142 mm dropout, replaceable hanger, tapered headtube
Suspension Fork
Schwinn carbon disc, 700c, aluminum tapered steerer, 12 mm x 100 mm thru axle
Drivetrain
Rear Derailleur
Shimano GRX FD-RX400
Front Derailleur
Shimano GRX FD-RX400, 31.8 mm clamp
Shift Levers
Shimano GRX ST-RX400, 20-speed
Crank
FSA Omega Modular MegaEXO, 46/30T
Bottom Bracket
FSA MegaEXO, sealed external bearing, 68 mm
Chain
KMC X10
Pedals
Schwinn road, nylon, toe clips and straps
Wheels
Front Hub
Formula RX512, aluminum, 12 mm x 100 mm thru axle, 32H, 6-bolt
Rear Hub
Formula RX142, aluminum, 12 mm x 142 mm thru axle, 32H, 6-bolt
Rims
Alex DP21, aluminum, double wall, 32H, tubeless ready
Spokes
14G, stainless steel
Tires
Kenda Piedmont, 700c x 40c, wire bead
Brakes
Brakes
Shimano® hydraulic disc brakes
Cockpit
Stem
Promax, aluminum, threadless, - 6° rise, 31.8 mm clamp
Handlebar
TranzX ergo flare, double-butted aluminum, 31.8 mm clamp
Grips
Schwinn road, gel cork tape
Headset
Threadless, IS42 / IS52, semi-cartridge bearings
Seat
Saddle
Schwinn S1 sport, steel rails
Seatpost
Aluminum, 350 mm, 15 mm offset, 27.2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.33 mm | 1.37 mm | 1.43 mm | 1.48 mm |
| Bottom Bracket Height | 261 mm | 261 mm | 266 mm | 266 mm |
| Front Center | 611 mm | 616 mm | 621 mm | 635 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 41 mm | 39 mm | 38 mm | 38 mm |
| Stack | 512.9 mm | 533.9 mm | 559.6 mm | 588.2 mm |
| Reach | 385.7 mm | 389.1 mm | 392.2 mm | 397.5 mm |
| Top Tube Length | 549 mm | 564 mm | 579 mm | 599 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm | 560 mm |
| Head Tube Angle | 71.5 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 160 mm | 180 mm | 205 mm | 235 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1033 mm | 1038 mm | 1045 mm | 1059 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 70 mm | 70 mm |
| Standover Height | 749 mm | 772 mm | 803 mm | 850 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Vantage RX2 is part of the Schwinn Vantage model. 9 bikes variations carry this model name so far. Take a sneak peek at all Schwinn Vantage bikes models from 2020, by clicking here.
Model range prices
The most economical model, the Schwinn Vantage F3 2020 has a starting price of 539$. Schwinn Vantage RX1 2020 on the other hand is the most expensive at 1729$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Endurance bikes
According to our calculations, the average cost of an Endurance bike that is reliable is 2346$. However, you could also get a good Endurance bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1039$. In conclusion, this bike price is 125.79% smaller than the price of the average Endurance bike.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When it comes to wheels, the Vantage RX2 bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
