Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 170mm -
Travel Rear 160mm -
Fork RockShox ZEB Select
-
Groupset SLX, Shimano -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Battery Darfon 36V 720Wh, Shimano Steps service included -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 170cm
MD
165cm - 180cm
LG
175cm - 190cm
XL
185cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SCOR 4060 Z full carbon frame, Lower-Link Driven Instant Center Linkage, 160mm rear wheel travel, Fully guided internal cable routing, Boost 148, SRAM Universal Derailleur Hanger, Lower ISCG 05 mount / Chainguide
Suspension Fork
RockShox ZEB Select RC, 170mm travel, Charger R damper, DebonAir air spring, Compression adjust, Rebound adjust, 44mm rake, E-MTB rated
Rear Shock
RockShox Super Deluxe Select, Rebound adjust
Drivetrain
Rear Derailleur
Shimano Deore SLX (RD-M7100), 12 speed
Shift Levers
Shimano Deore XT (SL-M7100-R)
Cassette
Shimano Deore (CS-M6100-12), 10-51T, 12 Speed HYPERGLIDE+
Crank
Shimano FC-EM600, 165mm length, 34T Chainring (SM-CRE80-12-B)
Chain
Shimano Deore (CN-M6100)
Wheels
Front Hub
XDH-130, 32 spokes, Sealed cartridge bearings hubs
Rear Hub
XDH-130, 32 spokes, Sealed cartridge bearings hubs
Rims
XDH-130, 32 spokes, Sealed cartridge bearings hubs, 6061-T6 alloy rim; welded joint, 30mm internal width, Tubeless ready
Tires
Maxxis Assegai 29 x 2.5" (F) / Maxxis Dissector 29 x 2.4" (R), Compound: 3C Maxx Grip (F) / 3C Maxx Terra (R), Casing: EXO+ (F) / Double Down (R), Tubeless ready
Brakes
Brakes
Shimano BR-M6120, BL-M6100 levers, SM-RT66 rotors; 203mm
Cockpit
Stem
SCOR Alloy Stem, 3D forged, 31.6mm bar bore, 35mm lenght, 0° angle
Handlebar
SCOR Alloy Bar, 31.8mm clamp, 800mm wide, 20mm rise, 5° up sweep - 9° back sweep
Seat
Saddle
Fizik Terra Alpaca X5
Seatpost
X-Fusion Manic, S 125mm, M 150mm, L/XL 170mm travel
Motor & Battery
Motor
Shimano Steps EP8 (DU-EP800)
Battery
Darfon 36V 720Wh, Shimano Steps service included
Remote
Shimano Steps EP8 Wireless Cycle Computer (SC-EM800)
Charger
Darfon Smart Plus 100-240V 4A EU
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.382 mm | 1.333 mm | 1.291 mm | 1.237 mm |
| Bottom Bracket Height | 348 mm | 348 mm | 348 mm | 348 mm |
| Front Center | 773 mm | 798 mm | 823 mm | 853 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 131 mm | 136 mm | 144 mm | 150 mm |
| Stack | 601 mm | 612 mm | 626 mm | 637 mm |
| Reach | 435 mm | 459 mm | 485 mm | 515 mm |
| Top Tube Length | 562 mm | 590 mm | 621 mm | 655 mm |
| Seat Tube Angle | 77.9 ° | 77.9 ° | 77.9 ° | 77.9 ° |
| Seat Tube Length | 400 mm | 425 mm | 440 mm | 470 mm |
| Head Tube Angle | 63.8 ° | 63.8 ° | 63.8 ° | 63.8 ° |
| Head Tube Length | 87 mm | 99 mm | 115 mm | 127 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1206 mm | 1230 mm | 1255 mm | 1285 mm |
| Bottom Bracket Drop | 21 mm | 21 mm | 21 mm | 21 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 170 cm | 180 cm | 190 cm | 200 cm |
About this model
4060 Z LT SLX completes the Scor E 4060 model. SCOR released 16 e-bikes variations of this model so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
The most economical model, the SCOR 4060 Z LT SLX USA 2022 has a starting price of 6599$. SCOR 4060 Z LT XT 2022 on the other hand is the most expensive at 8812$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Enduro e-bikes average price
According to our calculations, the average cost of an Enduro e-bike that is reliable is 4785$. However, this doesn’t mean that if you spend less money on an Enduro e-bike, you couldn’t get a decent one. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
When SCOR released this model in 2022, its price was 6688$. Comparing this to the average Enduro e-bike price, we see that the price is 39.77% more expensive.
Internal Cable Routing
It’s also important to mention the internal cable routing that this e-bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork
The RockShox ZEB Select is included from the factory. It has a travel distance of 170mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
SCOR 4060 Z LT SLX e-bike has the RockShox Super Deluxe Select model installed, and has a travel of 160mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
The wheels on 4060 Z LT SLX are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. SCOR 4060 Z LT SLX has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
SCOR 4060 Z LT SLX e-bike has 4 sizes, in the range of 155 cm – 200 cm (5.09 ft – 6.56 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
SCOR 4060 Z LT SLX comes with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
