Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 170mm -
Travel Rear 160mm -
Fork RockShox ZEB Select
-
Groupset Shimano -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Battery Darfon 36V | 720Wh | Shimano Steps service included -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 170cm
MD
165cm - 180cm
LG
175cm - 190cm
XL
185cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SCOR 4060 Z full carbon frame | Lower-Link Driven Instant Center linkage | 140 / 160mm rear travel | Fully guided internal cable routing | Boost 148 | SRAM UDH | Lower ISCG 05 mount / chainguide
Suspension Fork
RockShox ZEB Select RC | 170mm travel | 44mm rake
Rear Shock
RockShox Super Deluxe Select Suspension
Drivetrain
Cassette
Shimano Deore (CS-M6100-12) | 10-51T
Crank
Shimano FC-EM600 | 165mm length | 34T chainring (SM-CRE80-12-B)
Chain
Shimano Deore (CN-M6100)
Wheels
Rims
XDH-130 | 32 spokes | 6061-T6 alloy | welded joint | 30mm internal width | Tubeless ready
Tires
Maxxis Assegai 29 x 2.5" 3C MaxxGrip Exo+ TR (F) | Maxxis Dissector 29 x 2.4" 3C MaxxTerra DD TR (R)
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
SCOR Alloy Stem | 3D forged | 31.6mm bar bore | 35mm lenght | 0deg angle
Handlebar
SCOR Alloy Bar | 31.8mm clamp | 800mm wide | 20mm rise | 5° upsweep | 9° backsweep
Grips
VP VPG-125A
Seat
Saddle
Fizik Terra Alpaca X5
Seatpost
X-Fusion Manic | S 125mm | M 150mm | L / XL 170mm travel
Motor & Battery
Motor
Shimano Steps EP8 (DU-EP800)
Battery
Darfon 36V | 720Wh | Shimano Steps service included
Charger
Darfon Smart Plus 100-240V | 4A | EU
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.382 mm | 1.333 mm | 1.291 mm | 1.237 mm |
| Bottom Bracket Height | 350 mm | 350 mm | 350 mm | 350 mm |
| Front Center | 773 mm | 798 mm | 823 mm | 853 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 134 mm | 140 mm | 147 mm | 153 mm |
| Stack | 601 mm | 612 mm | 626 mm | 637 mm |
| Reach | 435 mm | 459 mm | 485 mm | 515 mm |
| Top Tube Length | 562 mm | 590 mm | 621 mm | 655 mm |
| Seat Tube Angle | 77.9 ° | 77.9 ° | 77.9 ° | 77.9 ° |
| Seat Tube Length | 400 mm | 425 mm | 440 mm | 470 mm |
| Head Tube Angle | 63.8 ° | 63.8 ° | 63.8 ° | 63.8 ° |
| Head Tube Length | 87 mm | 99 mm | 115 mm | 127 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1206 mm | 1230 mm | 1255 mm | 1285 mm |
| Bottom Bracket Drop | 19 mm | 19 mm | 19 mm | 19 mm |
| Standover Height | 722 mm | 731 mm | 739 mm | 749 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 170 cm | 180 cm | 190 cm | 200 cm |
About this model
4060 Z LT SLX completes the Scor E 4060 model. 16 e-bikes variations carry this model name so far. You can easily view all of the Scor E 4060 e-bikes models from 2023, here.
Model range prices
SCOR 4060 Z LT SLX 2023 is the most economical model, with a starting price of 7431$. SCOR 4060 Z ST XT 2023 on the other hand costs 9555$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Enduro e-bikes
According to our calculations, the average cost of an Enduro e-bike that is reliable is 4785$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, SCOR 4060 Z LT SLX price was 7431$. Comparing this to the average Enduro e-bike price, we see that the price is 55.3% higher.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
This e-bike has the RockShox ZEB Select fork installed. The fork’s travel is 170mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The shock that’s installed on this e-bike is RockShox Super Deluxe Select Suspension, with a travel distance of 160mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
When it comes to wheels, the 4060 Z LT SLX e-bike is equipped with the 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
When you want to stop the bike in time, the brakes are vital. The 4060 Z LT SLX has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
SCOR 4060 Z LT SLX e-bike has 4 sizes, in the range of 155 cm – 200 cm (5.09 ft – 6.56 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Every bike should have a dropper post, and this one does. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
