Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 150mm -
Travel Rear 140mm -
Fork RockShox ZEB
-
Groupset SLX, Shimano -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Battery Darfon 36V 720Wh, Shimano Steps service included -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 170cm
MD
165cm - 180cm
LG
175cm - 190cm
XL
185cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SCOR 4060 Z full carbon frame, Lower-Link Driven Instant Center Linkage, 140mm rear wheel travel, Fully guided internal cable routing, Boost 148, SRAM Universal Derailleur Hanger, Lower ISCG 05 mount / Chainguide
Suspension Fork
RockShox ZEB, 150mm travel, Charger R damper, DebonAir air spring, Rebound adjust, 44mm rake, E-MTB rated
Rear Shock
RockShox Super Deluxe Select, Rebound adjust
Drivetrain
Rear Derailleur
Shimano Deore SLX (RD-M7100), 12 speed
Shift Levers
Shimano Deore XT (SL-M7100-R)
Cassette
Shimano Deore (CS-M6100-12), 10-51T, 12 Speed HYPERGLIDE+
Crank
Shimano FC-EM600, 165mm length, 34T Chainring (SM-CRE80-12-B)
Chain
Shimano Deore (CN-M6100)
Wheels
Front Hub
XDH-130, 32 spokes, Sealed cartridge bearings hubs
Rear Hub
XDH-130, 32 spokes, Sealed cartridge bearings hubs
Rims
XDH-130, 32 spokes, Sealed cartridge bearings hubs, 6061-T6 alloy rim; welded joint, 30mm internal width, Tubeless ready
Tires
Maxxis Assegai 29 x 2.5" (F) / Maxxis Dissector 29 x 2.4" (R), Compound: 3C Maxx Grip (F) / 3C Maxx Terra (R), Casing: EXO+ (F) / Double Down (R), Tubeless ready
Brakes
Brakes
Shimano BR-M6120, BL-M6100 levers, SM-RT66 rotors; 203mm
Cockpit
Stem
SCOR Alloy Stem, 3D forged, 31.6mm bar bore, 35mm lenght, 0° angle
Handlebar
SCOR Alloy Bar, 31.8mm clamp, 800mm wide, 20mm rise, 5° up sweep - 9° back sweep
Seat
Saddle
Fizik Terra Alpaca X5
Seatpost
X-Fusion Manic, S 125mm, M 150mm, L/XL 170mm travel
Motor & Battery
Motor
Shimano Steps EP8 (DU-EP800)
Battery
Darfon 36V 720Wh, Shimano Steps service included
Remote
Shimano Steps EP8 Wireless Cycle Computer (SC-EM800)
Charger
Darfon Smart Plus 100-240V 4A EU
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.374 mm | 1.325 mm | 1.289 mm | 1.233 mm |
| Bottom Bracket Height | 340 mm | 340 mm | 340 mm | 340 mm |
| Front Center | 752 mm | 777 mm | 802 mm | 832 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 115 mm | 120 mm | 126 mm | 131 mm |
| Stack | 599 mm | 611 mm | 625 mm | 636 mm |
| Reach | 436 mm | 461 mm | 485 mm | 516 mm |
| Top Tube Length | 561 mm | 590 mm | 621 mm | 655 mm |
| Seat Tube Angle | 78 ° | 78 ° | 78 ° | 78 ° |
| Seat Tube Length | 400 mm | 425 mm | 440 mm | 470 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 87 mm | 99 mm | 115 mm | 127 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1185 mm | 1210 mm | 1235 mm | 1265 mm |
| Bottom Bracket Drop | 29 mm | 29 mm | 29 mm | 29 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 170 cm | 180 cm | 190 cm | 200 cm |
Model Overview
4060 Z ST SLX completes the Scor E 4060 model. SCOR launched 16 e-bikes of this model so far. You can easily view all of the Scor E 4060 e-bikes models from 2022, here.
Model range prices
SCOR 4060 Z LT SLX USA 2022 is the cheapest e-bike model and costs 6599$. SCOR 4060 Z LT XT 2022 is the most expensive one and costs 8812$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail e-bikes
If you want an acceptable Trail e-bike you should know that the average price is 3365$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
This e-bike was released in 2022 and its price was 6688$. Comparing this to the average Trail e-bike price, we see that the price is 98.75% more expensive.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
4060 Z ST SLX components
Fork
SCOR 4060 Z ST SLX 2022 e-bike is equipped with the RockShox ZEB fork, and has 150mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
As for the rear shock, this e-bike has the RockShox Super Deluxe Select model, with a travel of 140mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
The wheels on 4060 Z ST SLX are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. SCOR 4060 Z ST SLX is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 155 cm – 200 cm (5.09 ft – 6.56 ft). In short, you can easily find one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
