Spot Brand Mayhem 27.5″+ 4-Star Build 2018
2018 Mountain
Estimate price |
4,399$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 130mm -
Travel Rear 130mm -
Fork Fox Performance Float 34
-
Groupset GX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
FOX Performance 34, Boost, GRIP 3 damper
Rear Shock
FOX Performance Float DPS EVOL, 3 position adjust, 200mm x 57mm
Drivetrain
Rear Derailleur
SRAM GX Eagle
Front Derailleur
N/A
Shift Levers
SRAM GX Eagle, 12-speed
Cassette
SRAM XG-1275, 12-speed, 10-50 tooth
Crank
SRAM FC GX Eagle, 170mm length
Bottom Bracket
SRAM GXP, 73mm
Chain
SRAM GX Eagle
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Race Face Aeffect Plus, Boost front and rear
Rear Hub
Race Face Aeffect Plus, Boost front and rear
Rims
Race Face Aeffect Plus, tubeless
Tires
Schwalbe Rocket Ron 2.8"
Brakes
Brakes
SRAM Guide R with Centerline 180mm front/160mm rear rotors, 6-bolt
Brake Levers
SRAM Guide R
Cockpit
Stem
Race Face Aeffect, 60mm length, 35mm clamp
Handlebar
Race Face Aeffect, alloy, 760mm width, 20mm rise, 35mm diameter
Grips
ODI Vans
Headset
Cane Creek 40, ZS44 upper, ZS56 lower
Seat
Saddle
WTB Silverado Pro
Seatpost
FOX Performance Elite
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.45 mm | 1.39 mm | 1.34 mm |
| Bottom Bracket Height | 338 mm | 338 mm | 338 mm | 338 mm |
| Stack | 601 mm | 611 mm | 620 mm | 629 mm |
| Reach | 399 mm | 422 mm | 446 mm | 468 mm |
| Top Tube Length | 559 mm | 584 mm | 610 mm | 636 mm |
| Seat Tube Angle | 75.2 ° | 75.2 ° | 75.2 ° | 75.2 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 66.2 ° | 66.2 ° | 66.2 ° | 66.2 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm | 446 mm |
| Wheelbase | 1151 mm | 1174 mm | 1205 mm | 1239 mm |
| Bottom Bracket Drop | 17 mm | 17 mm | 17 mm | 17 mm |
| Standover Height | 697 mm | 702 mm | 708 mm | 714 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Mayhem 27.5″+ 4-Star Build is a Spotbrand Mayhem model. There are 25 bikes that carry this model name. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
The most economical model, the Spot Brand Mayhem 27.5″+ 4-Star Build 2018 has a starting price of 4399$. Spot Brand Mayhem 29″ 6-Star Build 2018 on the other hand is the most expensive at 6999$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2018 for 4399$. In conclusion, this bike price is 59.27% more expensive than the price of the average Trail bike.
Mayhem 27.5″+ 4-Star Build components
Fork
This bike has the Fox Performance Float 34 fork installed. The fork’s travel is 130mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The shock that’s installed on this bike is FOX Performance Float DPS EVOL, with a travel distance of 130mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
When it comes to wheels, the Mayhem 27.5″+ 4-Star Build bike is equipped with the 27.5″ aluminum model. These wheels will provide you with more control over the bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Spot Brand Mayhem 27.5″+ 4-Star Build is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Spot Brand Mayhem 27.5″+ 4-Star Build bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Spot Brand Mayhem 27.5″+ 4-Star Build includes a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
