Stevens E-Bormio Luxe Forma 2022
2022 E-bike
Estimate price |
3,554$
Weight | 23.8 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork Suntour NCX
-
Groupset Deore, Shimano -
Suspension Hardtail -
Motor Shimano 250W 60Nm mid-drive -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium 6061, O.L.D.: 135 mm, Brake: postmount disc 6", BB: Shimano Steps, Cable routing: internal, Fender + rack mounts
Suspension Fork
SR Suntour NCX-D Air LO, Travel: 63 mm, Air suspension, Lockout, Steerer 1 1/8", O.L.D.: 100 mm, Brake: postmount disc 6", Fender mounts
Drivetrain
Shift Levers
Shimano Deore, SL-M5130, 10-speed, Linkglide
Cassette
Shimano CS-LG600-10, 10-speed, Combination: 11-13-15-17-20-23-26-30-36-43 T
Crank
Shimano Steps E8000, FC-E8000, 44 T, BB type: Shimano Steps
Bottom Bracket
STEPS, press-fit
Chain
Shimano CN-LG500
Pedals
ATB Alu Pro Reflex
Wheels
Rims
Oxygen RM-T20 Disc, ETRTO: 20 x 622
Tires
Schwalbe Marathon, Tire size: 47-622, Endurance compound, GreenGuard, Reflective stripes
Brakes
Brakes
Shimano BR-MT410, Hydraulic disc brake
Brake Levers
Shimano BL-MT402-3A
Cockpit
Stem
Oxygen Versa II, adjustable, Handlebar clamp: 31.8 mm, Angle: adjustable (0° - 90°)
Handlebar
Oxygen Scorpo, Width: 680 mm, Backsweep: 5°, Rise: 25 mm, Clamp: 31.8 mm
Headset
STEVENS AH Taper 1 1/8"-1 1/2", Upper bearing cup: ZS44/28.6, Lower bearing cup: ZS55/40
Seat
Saddle
Selle Royal Nuvola Lady
Seatpost
Oxygen E-Scorpo, Length: 320 mm, Diameter: 30,9 mm, Insertion depth: min. 100 mm
Motor & Battery
Motor
Shimano Steps E6100, Continuous rated power: 250 W, Max. torque: 60 Nm, Breakaway at 25 km/h (15.5 mph), No of notches: 3 drive modes with support levels 70-230 % plus walk assistance, Mileage shimano-steps.com
Remote
Shimano SC-E5000
Charger
Shimano 2A charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 52cm | 56cm | Measuring mode |
|---|---|---|---|---|
| Stack Reach Ratio | 1.6 mm | 1.578 mm | 1.654 mm | mm |
| Bottom Bracket Height | 295 mm | 295 mm | 295 mm | mm |
| Front Center | 654 mm | 669 mm | 679 mm | mm |
| Rake | 42 mm | 42 mm | 42 mm | mm |
| Trail | 99 mm | 99 mm | 99 mm | mm |
| Stack | 608 mm | 617 mm | 645 mm | mm |
| Reach | 380 mm | 391 mm | 390 mm | mm |
| Top Tube Length | 566 mm | 580 mm | 587 mm | mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | ° |
| Seat Tube Length | 165 mm | 165 mm | 165 mm | mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | ° |
| Head Tube Length | 150 mm | 160 mm | 190 mm | mm |
| Chainstay Length | 472 mm | 472 mm | 472 mm | mm |
| Wheelbase | 1118 mm | 1133 mm | 1143 mm | mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | mm |
| Standover Height | 452 mm | 452 mm | 452 mm | mm |
| Wheels | 700 | 700 | 700 | 700 |
Model Overview
E-Bormio Luxe Forma is part of the Stevens E E Bormio model. 6 e-bikes variations carry this model name so far. Take a sneak peek at all Stevens E E Bormio e-bikes models from 2022, by clicking here.
Model range prices
Stevens E-Bormio Forma 2022 is the most affordable e-bike of this model and has a price of 2866$. On the other hand, Stevens E-Bormio Luxe Gent 2022, is the most expensive and costs 3290$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Commuter e-bikes
If you want an acceptable Commuter e-bike you should know that the average price is 2569$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Commuter e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2022 for 3290$. Comparing the average cost of a Commuter e-bike to this one, you will see that E-Bormio Luxe Forma price is 28.07% higher.
Average weight for Commuter e-bikes
On a deeper look, we notice that the average weight of a Commuter e-bike is 25.2 kg (55.56 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
With a weight of 23.8 kg (52.47 lbs), Stevens e-bike is a bit lighter than average. In conclusion, the average Commuter e-bike weighs 5.88% more than E-Bormio Luxe Forma.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
E-Bormio Luxe Forma components
Fork
This e-bike has the Suntour NCX fork installed. The fork’s travel is 63mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The wheels on E-Bormio Luxe Forma are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Stevens E-Bormio Luxe Forma has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
